Запчасти John Deere 7C ZTS 591 - SIDE ENTRY CAB PILOT HOSES FROM SIGNAL MANIFOLD (48 INCH RISER) 3363 LINES, HOSES & FITTINGS

1

FFSB111390

Hydraulic Hose

(TO LEFT JOYSTICK)

1шт.

2

FFSB111391

Hydraulic Hose

(TO LEFT JOYSTICK)

1шт.

3

FFSB111393

Hydraulic Hose

(TO LEFT JOYSTICK)

1шт.

4

FFSB111392

Hydraulic Hose

(TO LEFT JOYSTICK)

1шт.

5

FFSB111403

Hydraulic Hose

(TO PILOT SHUT-OFF VALVE)

1шт.

6

FFSB111402

Hydraulic Hose

(TO PILOT SHUT-OFF VALVE)

1шт.

7

FFSB111404

Hydraulic Hose

(TO PILOT SHUT-OFF VALVE)

1шт.

8

FFSB111405

Hydraulic Hose

(TO PILOT SHUT-OFF VALVE)

1шт.

9

FFSB111400

Hydraulic Hose

(TO TRAVEL VALVE)

1шт.

10

FFSB111398

Hydraulic Hose

(TO TRAVEL VALVE)

1шт.

11

FFSB111401

Hydraulic Hose

(TO TRAVEL VALVE)

1шт.

12

FFSB111399

Hydraulic Hose

(TO TRAVEL VALVE)

1шт.

13

FFSB111394

Hydraulic Hose

(TO RIGHT JOYSTICK)

1шт.

14

FFSB111396

Hydraulic Hose

(TO RIGHT JOYSTICK)

1шт.

15

FFSB111397

Hydraulic Hose

(TO RIGHT JOYSTICK)

1шт.

16

FFSB111395

Hydraulic Hose

(TO RIGHT JOYSTICK)

1шт.

17

4200467

Adapter Fitting

(SUB FOR FFSB109412, TH108417)

4шт.

18

R43302

Tie Band

(SUB FOR FFSB108110)

5шт.

19

24M7096

Washer

10.500 X 18 X 1.600 mm (SUB FOR FFSB107709)

8шт.

20

12M7066

Lock Washer

10 mm (SUB FOR FFSB107409)

8шт.

21

14M7274

Nut

M10 (SUB FOR FFSB107411)

8шт.

22

FFSB110347

Clamp

4шт.

23

FFSB107369

Nut

1шт.

24

FFSB110137

Clamp

2шт.

25

FFSB105405

Clamp

2шт.

26

19M7402

Cap Screw

M10 X 25 (SUB FOR FFSB1 07461)( FFSB106133 NLA)

2шт.

12M7066

Lock Washer

10 mm

2шт.

24M7296

Washer

10.500 X 30 X 2.500 mm

2шт.

27

F010967

Hose Support

(SUB FOR FFSB104269)

3шт.

28

19M7402

Cap Screw

M10 X 25 (SUB FOR FFSB107461)

4шт.

12M7066

Lock Washer

10 mm

4шт.

24M7028

Washer

10.500 X 20 X 2 mm

4шт.

29

19M7935

Cap Screw

M10 X 55 (SUB FOR FFSB107954)

2шт.

30

FFSB112976

Clamp

1шт.
