Запчасти John Deere 70CLC 119 - 5107 CYLINDER HEAD AND VALVES 0400B Engine 6068HT054-RE507967 6068HT054

Схема запчастей John Deere 70CLC - 119 - 5107 CYLINDER HEAD AND VALVES 0400B Engine 6068HT054-RE507967 6068HT054

Артикул

Название

Примечание

Количество

1

R48685

Dowel Pin

4шт.

2

T18891

Plug

2шт.

3

RE518527

Short Block Assembly

(MARKED R119565 ) (ORDER RE507643)

1шт.

4

RE57836

Pipe Plug

(SUB FOR 15H624)(WITHOUT TURBOCHARGER)

1шт.

5

R104592

Pipe Plug

6шт.

6

R119874

Bushing

(CAMSHAFT)

1шт.

7

R132518

Plate

1шт.

8

19M8999

Screw

M8 X 25

2шт.

9

R121043

Valve

(ENGINE OIL BYPASS)

1шт.

10

R111137

Spring

1шт.

11

RE505501

Bleed Valve

(OIL PRESSURE REGULATING)

1шт.

12

R116466

Plug

1шт.

13

R26650

Dowel Pin

2шт.

14

15H623

Pipe Plug

3/8"

1шт.

15

R115390

Bushing

1шт.

16

R75892

O-Ring

1шт.

17

R114241

Bearing Cap

(MAIN BEARING)

6шт.

18

T20168

Washer

14шт.

19

T23474

Cap Screw

14шт.

20

R132186

Bearing Cap

(MAIN THRUST BEARING)

1шт.

21

R131182

Orifice

6шт.

22

RE508185

Fitting

2шт.

23

U13639

O-Ring

2шт.

24

PM38655

Sealant

(SUB FOR T43514)(PLASTIC GASKET)

1шт.

25

R123616

Plug

(WITH CAB HEAT)

1шт.

26

51M7043

O-Ring

15.300 X 2.200 mm (WITH CAB HEAT)

1шт.

27

RE507952

Drain Valve

(WITH CAB HEAT)

1шт.

28

AT13740

Drain Valve

1шт.

29

RE55145

Switch

(OIL PRESSURE)

1шт.

Выбрано товаров: 29
