1
T115957
ADAPTER
(SUB FOR T110867)
4шт.
2
T110034
RETAINER
3шт.
3
T111652
OIL LINE
BOOM
1шт.
4
AT110455
OIL LINE
BOOM
1шт.
5
AT111516
OIL LINE
(SUB FOR AT110456) ARM
1шт.
6
AT110457
OIL LINE
ARM
1шт.
7
AT111517
OIL LINE
(SUB FOR AT110458) BUCKET
1шт.
8
AT110459
OIL LINE
BUCKET
1шт.
9
12M7056
LOCK WASHER
8 MM, (SUB FOR 12M7065)
6шт.
10
19M8324
CAP SCREW
M10 X 16, (SUB FOR 19M7557, THIS APPLICATION)
2шт.
24M7296
WASHER
10.500 X 30 X 2.500 MM, (SUB FOR T110607)
2шт.
11
M800452
SCREW WITH WASHER
4шт.
12
14M7273
NUT
M8
6шт.
13
T110599
CLAMP
4шт.
14
T111104
HYDRAULIC HOSE - FABRICATE
ARM
2шт.
15
T111105
HYDRAULIC HOSE - FABRICATE
BOOM
2шт.
16
T111106
HYDRAULIC HOSE - FABRICATE
ARM
2шт.
17
T111106
HYDRAULIC HOSE - FABRICATE
BUCKET
2шт.
18
T111106
HYDRAULIC HOSE - FABRICATE
BOOM
2шт.
19
T111107
HYDRAULIC HOSE - FABRICATE
BUCKET
2шт.
20
T111124
SLEEVE
(FOR USE WITH CANOPY)
2шт.
21
T111125
SLEEVE
(FOR USE WITH CANOPY)
2шт.
22
T111123
SLEEVE
(FOR USE WITH CANOPY)
2шт.
23
T111653
TIE BAND
(FOR USE WITH CANOPY)
4шт.
24
T111126
CLAMP
8шт.
25
T111014
HOSE
2шт.
26
12M7066
LOCK WASHER
10 MM
2шт.
19M7166
CAP SCREW
M10 X 20
2шт.
