Запчасти John Deere 5 12 - HYDRAULIC SYSTEM RESERVOIR HOSES 2160 - MAIN HYDRAULIC SYSTEM 21

1

T110183

ELECTRICAL CONNECTOR ASSY

(SUB AT111532)

1шт.

AT111532

FITTING

1шт.

2

T111098

FITTING

1шт.

3

4154653

ADAPTER

(SUB FOR T110871) (SUB FOR TH100989)

1шт.

4

4154656

ELBOW FITTING

(SUB FOR T110861) (SUB FOR TH101588)

1шт.

5

4154656

ELBOW FITTING

(SUB FOR T110861) (SUB FOR TH101588)

1шт.

6

4156433

ELBOW FITTING

(SUB FOR T111099) (SUB FOR TH101971)

1шт.

7

4506418

O-RING

(SUB FOR T110438) (SUB FOR U46489)

1шт.

8

NUT

(SUB AT111532) ( T110513 NO LONGER AVAILABLE)

1шт.

9

RING

(SUB AT111532) ( T110514 NO LONGER AVAILABLE)

1шт.

10

T110590

PACKING

1шт.

11

T110591

BACK-UP RING

(SUB AT111534)

1шт.

12

T110602

NUT

1шт.

13

T111352

FITTING

1шт.

AT111534

FITTING

1шт.

14

AT110072

LINE

1шт.

15

12M7066

LOCK WASHER

10 MM

2шт.

19M7402

CAP SCREW

M10 X 25

2шт.

16

AT132513

HYDRAULIC HOSE - FABRICATE

(SUB FOR T111117)

1шт.

17

AH111269

HYDRAULIC HOSE

(SUB FOR T111118)

1шт.

18

T111120

HYDRAULIC HOSE - FABRICATE

1шт.

19

T111121

HYDRAULIC HOSE - FABRICATE

1шт.

20

T111122

HYDRAULIC HOSE

1шт.

21

WZ2141223

HOSE CLAMP

(SUB FOR T110427) (SUB FOR AA34965)

1шт.

22

M800675

CLAMP

1шт.

23

M800674

HOSE CLAMP

1шт.

24

FITTING

(SUB AT111532)

1шт.

25

FITTING

(SUB AT111534)

1шт.
