1
AR85517
Adapter Fitting
1шт.
2
AT186577
Kit
D10W HEATER (DEERE DEALER OR DER DIRECT FROM ACTIVE GEAR)
1шт.
3
AT186578
Kit
SWITCH AND LED (DEERE DEALER ORDER DIRECT FROM ACTIVE GEAR)
1шт.
4
AT186671
Fitting
1шт.
5
H33801
Hose Fitting
2шт.
6
R123226
Seal
1шт.
7
R123345
Gasket
1шт.
8
R501373
Gasket
(SUB FOR R54638)
1шт.
9
TY22466
Clamp
4шт.
10
Housing
THERMOSTAT ( T166547 NO LONGER AVAILABLE)
1шт.
11
T166548
Plug
1шт.
12
U13639
O-Ring
2шт.
13
R46667
Clamp
ARшт.
14
24M7027
Washer
5.300 X 10 X 1 mm
2шт.
15
24M7239
Washer
10.700 X 21 X 2.500 mm
4шт.
16
Bracket
HEATER MOUNTING, RH ( T16 6544 NO LONGER AVAILABLE)
1шт.
17
Bracket
HEATER MOUNTING, LH ( T16 6545 NO LONGER AVAILABLE)
1шт.
18
T166818
Label
(SUB FOR T166602)(ARCTIC START)
1шт.
19
T166628
Bracket
1шт.
20
T166629
Tube
1шт.
21
T166636
Hose
OUTLET, 0.75 IN ID X 1.06 IN OD X 86.0 IN LG, MAKE FROM T78497 BULK ROLL, CUT TO SIZE
1шт.
22
T166637
Hose
INLET, 0.75 IN ID X 1.06 IN OD X 46 IN LG , MAKE FROM T78497 BULK ROLL, CUT TO SIZE
1шт.
23
12M7033
Lock Washer
10.500 mm
1шт.
24
14M7297
Nut
M5
1шт.
25
14M7400
Lock Nut
M10
4шт.
26
19M7372
Cap Screw
M5 X 16
1шт.
27
19M7572
Cap Screw
M10 X 45
4шт.
28
12M7006
Lock Washer
6 mm USED ON EXHAUST PIPE CLAMP
1шт.
29
24M7105
Washer
6 X 12 X 1.600 mm USED ON EXHAUST PIPE CLAMP
4шт.
30
14M7272
Nut
M6 USED ON EXHAUST PIPE CLAMP
1шт.
31
24H1325
Washer
15/32" X 59/64" X 0.065"
1шт.
32
AT190894
Kit
START (ARTIC) (SUB FOR AT186576 ) (INC LUDES AT190750 AND AT190749 WHOLEGOODS)
1шт.
