1
19M7402
Cap Screw
M10 X 25
2шт.
12M7058
Lock Washer
12 mm (SUB FOR 12M7067)
2шт.
24M7346
Washer
11 X 20 X 2 mm
2шт.
46
24M7028
Washer
10.500 X 20 X 2 mm
4шт.
48
L159272
Screw
(SUB FOR AT213615 OR J781040)
4шт.
50
12H317
Lock Washer
9/16"
3шт.
51
24M7085
Washer
15 X 28 X 2.500 mm
3шт.
52
4204136
Clip
(SUB FOR TH4204136)
1шт.
53
4436535
Sensor
(SUB FOR TH4436535)
4шт.
54
19M7662
Cap Screw
M10 X 30
1шт.
12M7066
Lock Washer
10 mm
1шт.
55
8082452
Bracket
(SUB FOR TH8082452)
1шт.
56
19M6332
Cap Screw
M14 X 35
3шт.
58
4219918
Isolator
(SUB FOR TH111416)
1шт.
59
H77698
Tie Band
5шт.
61
4630938
Hydraulic Hose
ALSO ORDER 4202422 AND 4455585, (SUB FOR TH4452046) 4452046 NLA)
1шт.
4202422
Adapter Fitting
1шт.
4455585
Reducer
1шт.
63
4630941
Hydraulic Hose
Arm In ALSO ORDER 4455585 4202 422 AND H77698, SUB FOR 4452047
1шт.
4455585
Reducer
1шт.
4202422
Adapter Fitting
1шт.
H77698
Tie Band
1шт.
65
4630940
Hydraulic Hose
Right Swing ALSO ORDER 4455585 42 02422 AND H77698, SUB FOR 4452048)
1шт.
4455585
Reducer
1шт.
4202422
Adapter Fitting
1шт.
H77698
Tie Band
1шт.
66
4452049
Oil Line
Bucket Curl (SUB FOR TH4452049)
1шт.
69
4452050
Oil Line
Left Propel Reverse (SUB FOR TH4452050)
1шт.
71
4452051
Oil Line
Right Propel Reverse (SUB FOR TH4452051)
1шт.
72
4420392
Fitting
(SUB FOR TH4420392)
6шт.
72A
CH11570
O-Ring
13.800 X 2.400 mm (0.543" X 3/32")
1шт.
74
4468337
Flow Control Hyd. Valve
(SHUTTLE)
1шт.
4486321
Valve
Shuttle
1шт.
