1
FFSB100133
Arm
1шт.
2
FFSB100128
Oil Line
1шт.
3
FFSB100129
Oil Line
1шт.
4
FFSB100130
Oil Line
1шт.
5
FFSB100131
Oil Line
1шт.
6
FFSB100132
Oil Line
1шт.
7
FFSB107257
Pin Fastener
(SUB FOR FFSB102450)
1шт.
8
FFSB107208
Pin Fastener
(SUB FOR FFSB100057)
1шт.
FFSB105628
Pin
1шт.
FFSB107208
Pin Fastener
(SUB FOR FFSB100057)
1шт.
FFSB105628
Pin
1шт.
9
FFSB105951
Wear Plate
(SUB FOR TH108944, THIS APPLICATION)
2шт.
10
FFSB105952
Wear Plate
(SUB FOR TH108944, THIS APPLICATION)
2шт.
11
19M8043
Cap Screw
M16 X 140
1шт.
12
14M7276
Nut
M16
2шт.
13
3055205
Bushing
(SUB FOR FFSB100054)
2шт.
14
19M8100
Cap Screw
M20 X 180
1шт.
15
14M7277
Nut
M20 (SUB FOR 14M7144)
2шт.
16
19H1726
Cap Screw
3/8" X 2-1/4"
16шт.
FFSB100114
Reinforcement
8шт.
FFSB100115
Lock Nut
16шт.
FFSB100112
Half Clamp
8шт.
17
19H1726
Cap Screw
3/8" X 2-1/4"
4шт.
FFSB100114
Reinforcement
2шт.
FFSB100115
Lock Nut
4шт.
FFSB100113
Half Clamp
2шт.
21
H75541
Clamp
(SUB FOR FFSB102223)
2шт.
22
Adapter Fitting
( FFSB102147 NOT AVAILABLE FOR SERVICE)
2шт.
22A
38H1281
Union Fitting
1шт.
22B
T76938
O-Ring
23.520 X 1.780 mm
2шт.
23
Adapter Fitting
( FFSB102148 NOT AVAILABLE FOR SERVICE)
3шт.
23A
38H1272
Union Fitting
1шт.
23B
T77858
O-Ring
18.771 X 1.778 mm
2шт.
24
X16-12HLO-S
Union Fitting
(SUB FOR FFSB102143)
2шт.
24A
T77858
O-Ring
18.771 X 1.778 mm
1шт.
24B
T76938
O-Ring
23.520 X 1.780 mm
1шт.
25
Adapter Fitting
( FFSB102538 NOT AVAILABLE FOR SERVICE)
2шт.
25A
38H1536
Elbow Fitting
1шт.
25B
T78715
Nut
36.525 mm
1шт.
25C
T76938
O-Ring
23.520 X 1.780 mm
1шт.
26
Adapter Fitting
( FFSB102539 NOT AVAILABLE FOR SERVICE)
2шт.
26A
38H1567
Elbow Fitting
1шт.
26B
T78707
Nut
30.175 mm
1шт.
26C
T77858
O-Ring
18.771 X 1.778 mm
1шт.
27
Adapter Fitting
( FFSB102540 NOT AVAILABLE FOR SERVICE)
2шт.
27A
38H1461
Elbow Fitting
1шт.
27B
T77858
O-Ring
18.771 X 1.778 mm
1шт.
28
X4WGTX-WLN-S
Adapter Fitting
(SUB FOR FFSB102226)
3шт.
TH100074
Lubrication Fitting
3шт.
30
JD7769
Lubrication Fitting
(SUB FOR FFSB104342)
1шт.
31
T107303
Elbow Fitting
3шт.
32
4443885
Bushing
(SUB FOR FFSB100055)
2шт.
33
FFSB102459
Hydraulic Hose
1шт.
34
FFSB102449
Hydraulic Hose
2шт.
35
FFSB102453
Hydraulic Hose
1шт.
36
FFSB102454
Hydraulic Hose
1шт.
37
FFSB102455
Hydraulic Hose
1шт.
38
FFSB102456
Hydraulic Hose
1шт.
39
FFSB102460
Hydraulic Hose
1шт.
40
FFSB102458
Hydraulic Hose
1шт.
41
T28850
Elbow Fitting
(SUB FOR FFSB104587)
1шт.
