Запчасти John Deere 200LC, 330LC, 370 117 - HEEL RACK 3340 BACKHOE AND EXCAVATOR FRAMES

1

FFSB100070

Grapple

1шт.

FFSB102727

Arch

1шт.

2

FFSB107256

Pin Fastener

(SUB FOR FFSB100071)

1шт.

FFSB107292

Pin Fastener

(SUB FOR FFSB102820)

1шт.

3

FF105548

Pin

(SUB FOR FFSB100069 AND FFSB107206)

1шт.

FF105537

Pin

(SUB FOR FFSB102819 AND FFSB107291)

1шт.

4

FFSB107208

Pin Fastener

(SUB FOR FFSB100057)

1шт.

FFSB107290

Pin Fastener

(SUB FOR FFSB102818)

1шт.

5

4144513

Washer

(SUB FOR TH102423)(1.2 MM)

3шт.

TH104296

Washer

(1 MM)

3шт.

TH104297

Washer

(2.3 MM)

1шт.

10

4075357

Washer

66 X 120 X 1 mm (SUB FOR TH108944)

2шт.

15

19M8100

Cap Screw

M20 X 180

2шт.

19M8503

Cap Screw

M20 X 160

2шт.

16

19M7954

Cap Screw

M16 X 150

1шт.

17

14M7277

Nut

M20

4шт.

18

38H1276

Adapter Fitting

2шт.

T77858

O-Ring

18.771 X 1.778 mm

2шт.

T78707

Nut

30.175 mm

2шт.

38H1216

Adapter Fitting

2шт.

T76938

O-Ring

23.520 X 1.780 mm

2шт.

R29936

O-Ring

29.743 X 2.946 mm

2шт.

19

38H1275

Adapter Fitting

2шт.

T77857

O-Ring

12.421 X 1.778 mm

2шт.

T78716

Nut

20.625 mm

2шт.

38H1321

Elbow Fitting

(SUB FOR FFSB102227)

2шт.

X6WLO-WLNL-S

Union Fitting

(SUB FOR FFSB103491)

2шт.

20

FFSB102079

Hydraulic Hose

(FOR USE WITH WBM GRAPPLE)

2шт.

FFSB102081

Hydraulic Hose

(FOR USE WITH JEWELL GRAPPLE)

2шт.

FFSB103305

Hydraulic Hose

(FOR UUSE WITH WBM GRAPPLE)

2шт.

21

FFSB102080

Hydraulic Hose

(FOR USE WITH WBM GRAPPLE)

2шт.

FFSB102082

Hydraulic Hose

(FOR USE WITH JEWELL GRAPPLE)

2шт.

FFSB103306

Hydraulic Hose

(FOR USE WITH WBM GRAPPLE)

2шт.

FFSB103307

Hydraulic Hose

(FOR USE WITH WBM GRAPPLE)

2шт.

22

14M7276

Nut

M16

2шт.

23

X6WLO-WLNL-S

Union Fitting

(SUB FOR FFSB103491)

1шт.

24

T77858

O-Ring

18.771 X 1.778 mm

1шт.
