0
9205229
Cab
Not Illustrated Contains All Items On This Page - Additional Components Liste d On Separate Pages (SUB FOR TH9205229)
1шт.
1
4474301
Door
Assembly
1шт.
2
4455979
Cover
(SUB FOR TH4455979)
1шт.
3
4369645
Handle
Outer (SUB FOR AT214145)
1шт.
4
4455975
Handle
Inner (SUB FOR TH4455975)
1шт.
5
4620431
Handle
Inner (SUB FOR 4474302, 4456173)
1шт.
6
4362135
Lock
(SUB FOR AT176789)
1шт.
7
4372091
Clip
(SUB FOR AT214290)
1шт.
8
4455982
Lock
(SUB FOR TH4455982)
1шт.
9
4455983
Rod
(SUB FOR TH4455983)
1шт.
10
4444664
Holder
(SUB FOR TH4444664)
1шт.
11
4456171
Wire
(SUB FOR TH4456171)
1шт.
12
4455981
Bushing
(SUB FOR TH4455981)
1шт.
13
4369661
U-Bolt
(SUB FOR AT214160)
1шт.
14
4666483
Hinge
( 4455980 NLA) (SUB FO R 4474303 OR TH4455980)
2шт.
15
R168831
Cap Screw
(SUB FOR AT214313, 4372261 OR 4356695)
ARшт.
24M7028
Washer
10.500 X 20 X 2 mm ( 24M7271 NLA)
ARшт.
16
4474304
Cover
1шт.
17
4455977
Isolator
(SUB FOR TH4455977)
1шт.
19
4455978
Weatherstrip
(SUB FOR TH4455978)
1шт.
20
4666484
Handrail
(SUB FOR 4453670 OR 4453670J)
1шт.
21
4372212
Screw With Washer
(USE WITH 4453670J) (SUB FOR AT214299)
2шт.
4463961
Bolt
(USE WITH 4666484)
2шт.
22
4453671
Sheet
(SUB FOR TH4453671)
1шт.
23
4382885
Bolt
(SUB FOR AT213624, M470625)
3шт.
12M7081
Lock Washer
6.400 mm (SUB FOR AT214314 OR 4372560)
3шт.
24
21M7246
Screw
M6 X 16
8шт.
26
4456172
Nut
(SUB FOR TH4456172)
1шт.
27
4414857
Nut
(SUB FOR AT157068)
4шт.
30
12M7006
Lock Washer
6 mm
8шт.
31
24M7293
Washer
6.500 X 13 X 1.600 mm
8шт.
50
4453676
Window
Bronze (SUB FOR TH4453676)
1шт.
4602582
Window
Green
1шт.
51
4453673
Frame
1шт.
52
Windowpane
(TH4448308, 4448308 NLA ) Bronze (SUB 4602564R)
1шт.
4602564R
Windowpane
Green (SUB FOR 4602564)
1шт.
53
Windowpane
Bronze (SUB FOR TH4448309 ) (SUB 4602565R ( 4448309 NLA))
1шт.
4602565R
Windowpane
Green (SUB FOR 4602565)
1шт.
54
4369653
Lock
(SUB FOR AT214152)
1шт.
55
J680410
Screw With Washer
(SUB FOR AT213608)
2шт.
56
4420531
Spacer
(SUB FOR AT214292, 4372093)
1шт.
57
4453675
Isolator
(SUB FOR TH4453675)
1шт.
58
4453674
Window
Felt Pad in Frame Chan nel (SUB FOR TH4453674)
1шт.
59
4147896
Spacer
(SUB FOR TH108646)
3шт.
61
4400087
Seal
(SUB FOR AT218141)
1шт.
65
4448310
Windowpane
Bronze (SUB FOR TH4468943, 4468943)
1шт.
4602566
Windowpane
Green
1шт.
72
4448315
Isolator
(SUB FOR TH4448315)
1шт.
