Запчасти John Deere 20 201 - ELECTRIC PARTS 1674 Wiring Harness And Switches

1

DH800101

Cover

SUB FOR AT200425, 4257035 N OT USED FOR THIS APPLICATION

1шт.

2

TY25803

Dry Charged Battery

AP33466 OR AT174338 NO T AVAILABLE FOR SERVICE

2шт.

3

14M7274

Nut

M10

4шт.

6

14M7025

Wing Nut

M10

2шт.

7

24M7028

Washer

10.500 X 20 X 2 mm

4шт.

8

DH800107

Cover

SUB FOR P60923

1шт.

9

4257034

Hook Bolt

SUB FOR AT155273

2шт.

10

8943795431

Relay

SUB FOR 4255762 AND AT154229 Battery

1шт.

11

21M7288

Screw

M6 X 10

2шт.

12

3056019

Cover

SUB FOR AT154139

1шт.

13

19M7932

Cap Screw

M8 X 16

3шт.

14

24M7055

Washer

8.400 X 16 X 1.600 mm

3шт.

16

AT145341

Relay

1-STARTER, 1-FUEL SHUT-OFF

2шт.

17

21M7267

Screw

M6 X 20

4шт.

12M7006

Lock Washer

6 mm

4шт.

19

AR45925

Battery Cable

482.600 mm (19") Battery To Ground

1шт.

22

4373214

Wiring Harness

SUB FOR AP34529

1шт.

24

14M7274

Nut

M10

1шт.

25

12M7066

Lock Washer

10 mm SUB FOR TY21766

1шт.

27

AP33487

Wiring Harness

1шт.

28

AP33486

Wiring Harness

1шт.

30

19M7402

Cap Screw

M10 X 25

1шт.

12M7066

Lock Washer

10 mm

1шт.

24M7028

Washer

10.500 X 20 X 2 mm

1шт.

31

AP33477

Bracket

1шт.

35

4448296

Wiring Harness

SUB FOR AT155617 Starter

1шт.
