1
Housing
(ORDER AT183675 OR AP35031)
1шт.
3
2036963
Shaft
(SUB FOR AT215848)
1шт.
4
2036965
Shaft
(SUB FOR AT215849)
1шт.
6
4339254
Tapered Roller Bearing
(SUB FOR AT215904)
2шт.
7
4348299
Bushing
(SUB FOR AT215919)
2шт.
8
4338325
Cylindrical Roller Bearing
(SUB FOR AT215903)
2шт.
9
4180790
Nut
M45 (SUB FOR TH109097)
2шт.
10
4331993
Thrust Washer
(SUB FOR AT215891)
1шт.
12
4340358
Seal
(SUB FOR AT215908)
2шт.
13
40M7182
Snap Ring
(SUB FOR AT215877 ) (SUB FOR 4086775)
2шт.
15
4233165
Fitting
(SUB FOR AT154164)
2шт.
16
M800650
Packing
2шт.
18
9742464
Piston
(SUB FOR AT216024)
14шт.
21
4339296
Shaft
(SUB FOR AT215905)
2шт.
22
4198956
Pin Fastener
5 X 10 mm (0.197" X 0. 394") (SUB FOR T107766)
2шт.
23
4180786
Compression Spring
(SUB FOR TH109105)
2шт.
25
2036958
Rotor
(SUB FOR AT215847)
2шт.
27
2036441
Flow Control Hyd. Valve
(SUB FOR AT215842)
1шт.
28
2037013
Flow Control Hyd. Valve
(SUB FOR AT215850)
1шт.
29
4179179
Dowel Pin
(SUB FOR TH109874)
4шт.
31
3075855
Link
(SUB FOR AT215874)
2шт.
32
9724756
Lever
(SUB FOR TH109873)
4шт.
33
4179177
Dowel Pin
6 X 10 mm (0.236" X 0.3 94") (SUB FOR TH109875)
4шт.
34
4179176
Dowel Pin
6 X 44 mm (0.236" X 1.7 32") (SUB FOR TH109876)
2шт.
35
CH17951
Ring
12шт.
36
4200227
Dowel Pin
(SUB FOR TH109878)
2шт.
41
1020401
Cylinder Head
(SUB FOR AT215835)
1шт.
42
3068226
Piston
(SUB FOR AT215856)
2шт.
43
4330909
Pin
(SUB FOR AT215888)
2шт.
44
4179838
Set Screw
M10 X 12 (SUB FOR TH109881)
2шт.
46
4355081
O-Ring
(SUB FOR AT215931)
2шт.
47
4330951
Stop
(SUB FOR AT215890)
2шт.
50
4355080
O-Ring
(SUB FOR AT215930)
2шт.
51
4330950
Stop
(SUB FOR AT215889)
2шт.
54
CH11560
Packing
20шт.
55
19M8439
Screw
M8 X 25
16шт.
56
4514388
Spring Washer
(SUB FOR TH101835)
16шт.
57
3071500
Back-Up Ring
(SUB FOR AT215867)
1шт.
58
34M7061
Spring Pin
8 X 20 mm
2шт.
59
4345061
O-Ring
(SUB FOR AT215911)
1шт.
60
19M8341
Screw
M12 X 45
10шт.
61
19M8547
Screw
M12 X 90 (SUB FOR AT127258 OR M341290)
2шт.
64
4436271
Sensor
(SUB FOR AT175981)
2шт.
64A
TH102560
O-Ring
15.800 X 2.400 mm (0.622" X 3/32")
1шт.
67
9134110
Fitting
(SUB FOR AT203649)
2шт.
67A
M800650
Packing
1шт.
69
9158023
Regulator
(SUB FOR AT183915)
2шт.
72
34M3845
Spring Pin
4 X 10 mm
4шт.
73
4343074
O-Ring
(SUB FOR AT213894)
4шт.
74
4348665
O-Ring
(SUB FOR AT213922)
2шт.
80
9134111
Fitting
(SUB FOR AT203648)
2шт.
80A
CH11570
O-Ring
13.800 X 2.400 mm (0.543" X 3/32")
1шт.
