Запчасти Hyundai HL760 AIR CONDITIONER MOUNTING(-#0153)

1-10

11L4-02290

11L4-02290-. Hose-Discharge

1-11

12L1-10340

12L1-10340-. Hose-Liquid(A)

1-12

11E6-36050

11E6-36050-. Receiver Drier Assy

1-13

14L4-00440

14L4-00440-. Hose-Liquid(B)

1-14

11E6-36100

11E6-36100-. Bracket-R/Drier

1-15

12L1-10370

12L1-10370-. Condenser Assy

1-5

11EF-0174

11EF-0174-. Bolt Assy

1-6

71L1-1037

71L1-1037-. Plate

1-7

12L3-0120

12L3-0120-. V-Belt

1-8

11E6-36030

11E6-36030-. Compressor Assy

1-9

14L4-00430

14L4-00430-. Hose-Suction

11

S017-100352

S017-100352-Bolt-Hex

12

S411-100002

S411-100002-Washer-Spring

13

S403-102002

S403-102002-Washer-Plain

14

S205-101002

S205-101002-Nut-Hex

15

S015-080252

S015-080252-Bolt-Hex

16

S017-100552

S017-100552-Bolt-Hex

2

71L1-1021

71L1-1021-Shroud Wa

20

S015-080202

S015-080202-Bolt-Hex

21

71L1-1028

71L1-1028-Plate

29

S552-050203

S552-050203-Clamp-Band

3

14L3-00740

14L3-00740-Resilient

30

S017-100252

S017-100252-Bolt-Hex

4

S015-080152

S015-080152-Bolt-Hex

5

S411-080002

S411-080002-Washer-Spring

6

S403-082002

S403-082002-Washer-Plain

N1

14L4-00450

14L4-00450-Aircon Assy

N1-16

71L1-1027

71L1-1027-. Fan Shroud Assy
