Запчасти Hyundai HL35C HEATER & AIRCON GROUP
№
Артикул
Название
Примечание
Количество
12L1-10360
12L1-10360-Evaporator Unit
12L1-10340
12L1-10340-Hose-Liquid(A)
12L1-10350
12L1-10350-Hose-Liquid
12L1-10320
12L1-10320-Hose-Discharge
12L1-10330
12L1-10330-Hose-Suction
11E6-36030
11E6-36030-Compressor Assy
12L1-10370
12L1-10370-Condenser Assy
11E6-36100
11E6-36100-Bracket-R/Drier
1
71L1-1029
71L1-1029-Box-Aircon,Heater
10
71L1-1006
71L1-1006-Hose-Liquid
11
11E6-36050
11E6-36050-R/Drier Assy
12
71L1-1036
71L1-1036-Bracket-R/Drier
13
71L1-1009
71L1-1009-Bracket-Comp Mtg
14
71L1-1010
71L1-1010-Bracket Wa
15
71L1-1012
71L1-1012-Pin
16
S601-010002
S601-010002-Ring-Retaining
17
71L1-1011
71L1-1011-V-Belt
18
71L1-1037
71L1-1037-Plate
19
71L1-1028
71L1-1028-Plate
2
71L1-1001
71L1-1001-Evaporator Unit
20
71L1-1035
71L1-1035-Tee
21
E127-3034
E127-3034-Heater Assy
22
21E3-4009
21E3-4009-Valve-Adjustable
23
21L1-4005
21L1-4005-Hose-Inlet
24
21L1-4002
21L1-4002-Hose-Outlet
25
21L1-4006
21L1-4006-Adapter
26
21L1-4004
21L1-4004-Hose-Inlet
28
21L1-4001
21L1-4001-Valve-Cut Off
29
E127-3136
E127-3136-Valve-Cut Off
3
71L1-1003
71L1-1003-Condenser Assy
31
S017-121402
S017-121402-Bolt-Hex
32
S017-100652
S017-100652-Bolt-Hex
33
S017-100252
S017-100252-Bolt-Hex
34
S017-080202
S017-080202-Bolt-Hex
36
S017-050152
S017-050152-Bolt-Hex
37
S017-100402
S017-100402-Bolt-Hex
38
S403-122002
S403-122002-Washer-Plain
4
71L1-1021
71L1-1021-Shroud Wa
40
S411-100002
S411-100002-Washer-Spring
42
S411-050002
S411-050002-Washer-Spring
43
S207-122002
S207-122002-Nut-Hex
44
71L1-1041
71L1-1041-Cover
45
S017-080152
S017-080152-Bolt-Hex
45
S017-080152
S017-080152-Bolt-Hex
46
S411-080002
S411-080002-Washer-Spring
46
S411-080002
S411-080002-Washer-Spring
6
71L1-1002
71L1-1002-Compressor Assy
7
71L1-1008
71L1-1008-Hose-Suction
8
71L1-1005
71L1-1005-Hose-Discharge
9
71L1-1007
71L1-1007-Hose-Liquid
N11
71L1-1004
71L1-1004-R/Drier Assy
N27
21L1-4007
21L1-4007-Lever-Control
N5
71L1-1027
71L1-1027-Fan-Shroud
Выбрано товаров: 55
