Запчасти Hyundai HL35C REAR PLANETARY GEAR 1(LH & RH)

3146863

3146863-Shim-P/Plate(4.5)

3200523

3200523-Shim-P/Plate(4.25)

3146873

3146873-Shim-P/Plate(5.0)

*

3198493

3198493-F/Planetary Gear-Lh

1

3198573

3198573-Cover

10

3127443

3127443-Bearing

11

3132833

3132833-Spacer

110

3198543

3198543-Support-Complete

12

3132823

3132823-Gear-Diff Pinion

13

3122773

3122773-Shim-Thrust Plate

14

3122723

3122723-Gear-Diff Side

15

70530

70530-Ring-Snap

16

3198633

3198633-Disk-Drum Brake

17

3146763

3146763-Disk-Brake

18

3146853

3146853-Shim-P/Plate(4.0)

19

3198643

3198643-Pin

2

70422

70422-Gasket

20

3122693

3122693-Ring-Snap

22

3143523

3143523-Spring

23

3138233

3138233-Ring

24

3128073

3128073-Plate-Small

25

3138173

3138173-Nut

26

70446

70446-Ring-Snap

27

3138383

3138383-Plate-Thrust

28

70567

70567-Bearing

29

3138163

3138163-Support-Wheel

3

3112993

3112993-Plate-Small

30

3198583

3198583-Wheel

31

3198563

3198563-Hub-Wheel

32

3147233

3147233-Bolt-Stud

33

70432

70432-Gasket

34

3198663

3198663-Piston

35

71304

71304-Gasket

36

70566

70566-Bearing

37

71196

71196-Gasket

39

70673

70673-Oil Breather

4

70311

70311-Screw

40

70382

70382-Screw

41

70565

70565-Gasket

43

3138103

3138103-Screw

44

3114173

3114173-Nut

45

71197

71197-Pin

46

3198673

3198673-Ring-Complete

47

71199

71199-Gasket

5

3198553

3198553-Support

6

3138303

3138303-Pin

7

70507

70507-Plug

8

70111-Z

70111-Z-Gasket

9

3127453

3127453-Shim-Thrust Plate

N*

3198483

3198483-F/Planetary Gear-Rh

N21

3198653

3198653-Plate-Pressure

N38

3198593

3198593-Spindle-W/Hub,Rh

N42

3198613

3198613-Spindle-W/Hub,Lh
