Запчасти Hyundai HL35C RADIATOR MOUNTING & PIPING

1

11L1-10021

11L1-10021-Radiator & Oil Cooler

10

S403-102002

S403-102002-Washer-Plain

11

S411-100002

S411-100002-Washer-Spring

12

S017-100352

S017-100352-Bolt-Hex

13

11L1-3002

11L1-3002-Brace

14

S205-101002

S205-101002-Nut-Hex

15

11L1-3015

11L1-3015-Hose-Outlet

16

11L1-3014

11L1-3014-Hose-Inlet

17

11L1-3010

11L1-3010-Hose-Air Vent

18

11L1-3009

11L1-3009-Hose-Make Up

19

11L1-3016

11L1-3016-Fitting

2

11L1-3021

11L1-3021-Plate-Rubber

20

S520-027000

S520-027000-Clamp-Hose

22

S520-001500

S520-001500-Clamp

23

S520-070000

S520-070000-Clamp-Hose

24

12101810

12101810-Cap-Radiator

3

S441-120002

S441-120002-Washer-Hardened

4

S017-120352

S017-120352-Bolt-Hex

5

11L1-3007

11L1-3007-Shroud

6

S411-080002

S411-080002-Washer-Spring

7

S017-080202

S017-080202-Bolt-Hex

8

11L1-3008

11L1-3008-Guard-Fan

9

11L1-1005

11L1-1005-Grommet

N1

11L1-1002

11L1-1002-Radiator & Oil Cooler
