Запчасти Hyundai HL35C TRANSMISSION PIPING

P600-202025

P600-202025-Hose Assy-Thd 0x0

82L1-3302

82L1-3302-Hose Assy

82L1-3302

82L1-3302-Hose Assy

P600-202042

P600-202042-Hose Assy-Thd 0x0

*

4168-034-028

4168-034-028-. Converter

1

12L1-0029

12L1-0029-Pipe

10

S201-101002

S201-101002-Nut-Hex

11

82L1-3303

82L1-3303-Hose Assy

13

81L1-3316

81L1-3316-Fitting

14

81L1-3306

81L1-3306-Elbow-45

15

82L1-3305

82L1-3305-Fitting

16

S631-038001

S631-038001-O-Ring

17

S017-100252

S017-100252-Bolt-Hex

18

S411-100002

S411-100002-Washer-Spring

18

S411-100002

S411-100002-Washer-Spring

19

82L1-3312

82L1-3312-Elbow-45

2

12L1-0024

12L1-0024-Pipe Wa

20

82L1-3308

82L1-3308-Hose Assy

21

82L1-3309

82L1-3309-Washer-Copper

22

82L1-3310

82L1-3310-Connector

23

P603-202036

P603-202036-Hose Assy-Thd

3

12L1-0030

12L1-0030-Hose

4

S520-040000

S520-040000-Clamp-Hose

5

12L2-0013

12L2-0013-Gasket

6

12L1-0031

12L1-0031-U-Bolt

7

S017-080302

S017-080302-Bolt-Hex

8

S411-080002

S411-080002-Washer-Spring

N*

12L1-0006

12L1-0006-T/M Assy
