Запчасти Hyundai HL35C HYDRAULIC TANK

@

@-Not Individually Supplied

E131-0256

E131-0256-Valve-Bypass

E131-0256

E131-0256-Valve-Bypass

1

31L1-01441

31L1-01441-Hyd Tank Wa

10

S411-100002

S411-100002-Washer-Spring

11

S441-160002

S441-160002-Washer-Hardened

12

31L1-4047

31L1-4047-Gauge-Sight

12-1

S641-049001

S641-049001-. O-Ring

13

31L1-4044

31L1-4044-Cover Wa

14

E131-0253

E131-0253-Air Breather

14-2

@

@-. Bolt-Sockct

14-2

@

@-. Bolt-Sockct

14-3

31E1-10380

31E1-10380-. Element-Filter

14-4

@

@-. Packing

14-5

31E1-10370

31E1-10370-. Bayonet Assy

14-6

31E1-10350

31E1-10350-. Casing

14-7

31E1-10360

31E1-10360-. Strainer

2

31L1-4041

31L1-4041-Element Assy

5

E131-0220

E131-0220-Spring

6

31E3-4526

31E3-4526-Cover

7

S632-160001

S632-160001-O-Ring

8

S017-100202

S017-100202-Bolt-Hex

9

S017-160352

S017-160352-Bolt-Hex
