Запчасти Hyundai HL25C RADIATOR

11L4-01351

11L4-01351-Radiator Assy

S015-080152

S015-080152-Bolt-Hex

S015-080152

S015-080152-Bolt-Hex

11L4-0175

11L4-0175-Sponge

11L4-0175

11L4-0175-Sponge

S411-080002

S411-080002-Washer-Spring

S411-080002

S411-080002-Washer-Spring

11L4-0140

11L4-0140-Pipe

S207-1210002

S207-1210002-Nut-Hex

11L4-0140

11L4-0140-Pipe

11L4-01391

11L4-01391-Shroud

1

11L4-0135

11L4-0135-Radiator Assy

1-1

12101810

12101810-. Cap-Radiator

12

S411-120002

S411-120002-Washer-Spring

13

S017-120302

S017-120302-Bolt-Hex

14

S017-120352

S017-120352-Bolt-Hex

15

S207-121002

S207-121002-Nut-Hex

16

11L4-1042

11L4-1042-Guard-Fan

2

11L4-0136

11L4-0136-Hose-Inlet

27

11L4-0174

11L4-0174-Guard-Fan

29

11L4-0189

11L4-0189-Rubber Plate

3

11L4-0137

11L4-0137-Hose-Outlet

30

11L4-0190

11L4-0190-Rubber Plate

31

11L4-0186

11L4-0186-Channel Wa

32

11L4-0187

11L4-0187-Channel Wa

33

S015-080202

S015-080202-Bolt-Hex

34

S403-083002

S403-083002-Washer-Plain

35

11L4-0194

11L4-0194-Sponge

36

11L4-0195

11L4-0195-Sponge

37

11L4-0192

11L4-0192-Screen Plate

38

11L4-0193

11L4-0193-Screen Plate

39

S017-120152

S017-120152-Bolt-Hex

4

11L4-0138

11L4-0138-Rod

40

S441-120002

S441-120002-Washer-Hardened

40

S441-120002

S441-120002-Washer-Hardened

41

11L4-0196

11L4-0196-Sponge

42

12L3-0143

12L3-0143-Plug

43

11L4-0198

11L4-0198-Plug

44

11L4-0199

11L4-0199-Connector

45

S520-015000

S520-015000-Clamp-Hose

46

S541-180002

S541-180002-Clamp-Tube

47

S401-062002

S401-062002-Washer-Plain

48

S411-060002

S411-060002-Washer-Spring

49

S015-060152

S015-060152-Bolt-Hex

5

11L4-0105

11L4-0105-Plate-Rubber

50

11E9-4107

11E9-4107-Hose-Vent

51

P710-062013

P710-062013-Hose

6

11L4-0104

11L4-0104-Bracket Wa

7

11L4-0139

11L4-0139-Shroud

8

S520-070000

S520-070000-Clamp-Hose
