Запчасти Hyundai HL25C HYDRAULIC LINES(MAIN)

1

31L4-0076

31L4-0076-Pipe Wa

10

31L4-0085

31L4-0085-Hose

11

31L4-0086

31L4-0086-Hose

12

31L4-0087

31L4-0087-Hose

13

31L4-0088

31L4-0088-Clamp

14

S520-100000

S520-100000-Clamp

15

S520-070000

S520-070000-Clamp

16

81L1-0048

81L1-0048-Flange-Split

17

31L4-0093

31L4-0093-Flange-Split

18

31L1-3029

31L1-3029-O-Ring

19

31L4-0072

31L4-0072-O-Ring

2

31L4-0077

31L4-0077-Pipe Wa

20

31L1-0032

31L1-0032-Hose Assy

21

31L1-0082

31L1-0082-Hose Assy

22

31L1-0058

31L1-0058-O-Ring

23

S017-120602

S017-120602-Bolt

24

S411-120002

S411-120002-Washer-Spring

25

S017-100352

S017-100352-Bolt-Hex

26

S017-100302

S017-100302-Bolt-Hex

27

S017-120402

S017-120402-Bolt-Hex

28

S017-100452

S017-100452-Bolt-Hex

29

S632-025001

S632-025001-O-Ring

3

31L4-0160

31L4-0160-Pipe Wa

30

S017-120452

S017-120452-Bolt-Hex

31

81L1-0051

81L1-0051-Bolt-Socket

32

31L4-0118

31L4-0118-Pipe Wa

33

31L4-5117

31L4-5117-Pipe Wa

34

S017-100252

S017-100252-Bolt-Hex

35

12L1-0031

12L1-0031-U-Bolt

36

S201-101002

S201-101002-Nut-Hex

37

S411-100002

S411-100002-Washer-Spring

38

31L4-3002

31L4-3002-Block

4

31L4-0079

31L4-0079-Pipe Wa

5

31L4-0080

31L4-0080-Pipe Wa

6

31L4-0081

31L4-0081-Pipe Wa

7

31L4-0082

31L4-0082-Hose

8

31L4-0083

31L4-0083-Hose

9

31L4-0084

31L4-0084-Hose
