Запчасти Hyundai R200W2 AIR CONDITIONER MOUNTING(R200W)

*

12E4-3500

12E4-3500-Air Con Assy-R12

1

12E1-3501

12E1-3501-. Cooling Unit

1-1

C34063E1

C34063E1-.. Expansion V/V

10

12E1-3514

12E1-3514-. Hose-Drain

11

12E1-3518

12E1-3518-. Switch Assy

12

12E1-3511

12E1-3511-. Adjuster

14

12E1-3510

12E1-3510-. Bracket-Comp Mount

15

E127-3141

E127-3141-. Joint-Component

16

12E1-3515

12E1-3515-. O-Ring

17

12E1-3516

12E1-3516-. O-Ring

17

12E1-3516

12E1-3516-. O-Ring

18

12E1-3517

12E1-3517-. O-Ring

19

S411-100002

S411-100002-Washer-Spring

2

12E1-3502

12E1-3502-. Compressor

20

S017-100252

S017-100252-Bolt-Hex

21

S017-100352

S017-100352-Bolt-Hex

22

S207-101002

S207-101002-Nut-Hex

23

S411-080002

S411-080002-Washer-Spring

24

S015-080202

S015-080202-Bolt-Hex

25

S015-060202

S015-060202-Bolt-Hex

26

S411-060002

S411-060002-Washer-Spring

27

S205-061002

S205-061002-Nut-Hex

28

S015-050102

S015-050102-Bolt-Hex

29

S411-050002

S411-050002-Washer-Spring

3

12E1-3503

12E1-3503-. Condenser Assy

30

12E3-3515

12E3-3515-Pulley

31

21E4-3014

21E4-3014-Harness-Air Con

4

12E1-3504

12E1-3504-. Receiver Dryer

5

11E4-3501

11E4-3501-. Hose Assy-Dis

6

12E1-3506

12E1-3506-. Hose Asst-Liquid(A)

7

12E1-3507

12E1-3507-. Hose Asst-Liquid(B)

8

12E1-3508

12E1-3508-. Hose Assy-Suction

9

12E1-3513

12E1-3513-. Bracket-R/Dryer
