Запчасти Hyundai R200W2 CONSOLE BOX ELECTRIC

21E1-10971

21E1-10971-Cpu Controller

21E4-1096

21E4-1096-. Plate-Instrument Panel

21E4-1096

21E4-1096-. Plate-Instrument Panel

21E4-1092

21E4-1092-Panel Assy 2

21E4-1092

21E4-1092-Panel Assy 2

21EK-00240

21EK-00240-Indicator Lamp Assy

21E4-00601

21E4-00601-Cluster Assy

21E4-10901

21E4-10901-. Decal-Panel

21E1-10810

21E1-10810-Cpu Controller

21E4-10961

21E4-10961-. Plate-Instrument Panel

21E4-1092

21E4-1092-Panel Assy 2

21E4-10420

21E4-10420-. Switch Assy(Ramlock)

10

21E4-1102

21E4-1102-Screw

11

21E4-2025

21E4-2025-Buzzer-Warning

12

21E4-4006

21E4-4006-Relay-Int Wiper

14

S411-050002

S411-050002-Washer-Spring

15

S161-040202

S161-040202-Screw

16

21E3-2001

21E3-2001-Sw-Cold Start Aid

17

S161-060202

S161-060202-Screw

18

S411-060002

S411-060002-Washer-Spring

19

S203-050002

S203-050002-Nut-Hex

20

S203-040002

S203-040002-Nut

21

S203-060002

S203-060002-Nut

22

71E3-0556

71E3-0556-Bracket-Fuse Box

23

S015-080252

S015-080252-Bolt-Hex

24

S411-080002

S411-080002-Washer-Spring

25

S203-080002

S203-080002-Nut-Hex

26

S541-360002

S541-360002-Clamp-Tube

27

S015-080162

S015-080162-Bolt-Hex

28

21E3-1020

21E3-1020-Wire-Link

29

21E4-1101

21E4-1101-Screw

3

21E4-1091

21E4-1091-Panel Assy 1

3-1

21E4-1093

21E4-1093-. Plate 1

3-2

E123-2533

E123-2533-. Switch-Heater

3-3

21E9-2003

21E9-2003-. Switch-Prolix

3-4

21E4-1089

21E4-1089-. Panel-Decal

3-5

21E4-1082

21E4-1082-. Decal-Blower

3-6

21E4-1083

21E4-1083-. Decal-Heater Lever

30

21E4-1103

21E4-1103-Screw

31

21EA-30270

21EA-30270-Plate

31-1

21E7-0313

21E7-0313-. Plug-Hole Blank

32

21E9-05530

21E9-05530-Bracket-Insert

33

S015-080202

S015-080202-Bolt-Hex

34

21E1-49760

21E1-49760-Plate

35

21E1-49770

21E1-49770-Plate

36

21E1-49750

21E1-49750-Harness-Ext

37

21E4-0057

21E4-0057-Plate

39

21E1-1097

21E1-1097-Cpu Controller

4

21E4-0024

21E4-0024-Lamp Assy-Indicator

40

21E9-4015

21E9-4015-Rubber-Mount

41

21E9-4018

21E9-4018-Prolix Resistor

42

S401-060002

S401-060002-Washer-Plain

43

S161-050252

S161-050252-Screw

43

S161-050252

S161-050252-Screw

44

21L1-0010

21L1-0010-Hour Meter

5

21E4-0103

21E4-0103-Relay Board Assy

5-1

21EA-3010

21EA-3010-. Plate Board

5-2

E125-2545

E125-2545-. Relay-5p

5-3

21E4-4005

21E4-4005-. Flasher Unit Assy

5-4

21E4-0011

21E4-0011-. Relay-4p

5-5

S161-060162

S161-060162-. Screw

5-6

S411-060002

S411-060002-. Washer-Spring

6-2

21E3-2015

21E3-2015-. Sw-Light

6-3

21E4-2029

21E4-2029-. Switch

6-4

21E9-2001

21E9-2001-. Switch-Toggle

6-5

21E6-0008

21E6-0008-. Cigar Lighter

6-6

21E4-2030

21E4-2030-. Switch-O/R D/Blade

6-7

21E4-1090

21E4-1090-. Decal-Panel

6-8

21E4-10410

21E4-10410-. Switch Assy(Parking)

7

21E4-0106

21E4-0106-Switch Assy-Micro

8

21E4-1099

21E4-1099-Fuse Box

8-1

21E1-49500

21E1-49500-. Fuse-10a

8-2

21E1-49490

21E1-49490-. Fuse-20a

8-3

21E1-49480

21E1-49480-. Fuse-30a

9

21E3-2002

21E3-2002-Switch-Micro

N1

21E4-0060

21E4-0060-Cluster Assy

N2

21E9-4001

21E9-4001-Cassette Radio

N38

21E4-4003

21E4-4003-Lamp-Controller
