Запчасти Hyundai R200W2 ATTACH HYD PIPING(PIN TYPE, 2 PCS BOOM)

31E1-50230

31E1-50230-Arm-Cylinder

31E1-50240

31E1-50240-Cylinder-Bucket

P683-127321

P683-127321-Hose Assy

P683-167321

P683-167321-Hose Assy

1

31E4-0039

31E4-0039-Cylinder-Boom,Lh

10

P680-167315

P680-167315-Hose Assy-Flg

11

P701-127328

P701-127328-Hose Assy-Flg 0x90

14

31E4-1083

31E4-1083-Pipe Assy

15

31E4-1084

31E4-1084-Pipe Assy

16

31E4-1093

31E4-1093-Pipe Assy

17

31E4-1086

31E4-1086-Pipe Assy

18

31E4-1087

31E4-1087-Pipe Assy

2

31E4-0040

31E4-0040-Cylinder-Boom,Rh

28

E131-0277

E131-0277-Pipe-Spacer

29

E131-0333

E131-0333-Clamp-Pipe

30

31E4-3133

31E4-3133-Clamp-Hose

35

P173-120102

P173-120102-Flange-Split

36

P173-160104

P173-160104-Flange-Split

37

CO0418A

CO0418A-O-Ring

38

CO0423A

CO0423A-O-Ring

4

E131-0294

E131-0294-Cylinder-Bucket

40

S017-100802

S017-100802-Bolt-Hex

41

S017-160602

S017-160602-Bolt-Hex

42

S109-100306

S109-100306-Bolt-Socket

43

S275-100002

S275-100002-Nut-Self Locking

44

S403-102002

S403-102002-Washer-Plain

46

S411-160002

S411-160002-Washer-Spring

5

P681-127322

P681-127322-Hose Assy-Flg

6

P681-167322

P681-167322-Hose Assy-Flg

7

E131-0259

E131-0259-Hose Assy

8

P680-127338

P680-127338-Hose Assy-Flg

9

P680-167338

P680-167338-Hose Assy-Flg

N3

E131-0293

E131-0293-Arm-Cylinder
