Запчасти Hyundai R200W2 LOWER HYD PIPING 1

1

31E4-0002

31E4-0002-Travel Motor

10

31E4-1041

31E4-1041-Pipe Assy

100

S411-160002

S411-160002-Washer-Spring

102

S205-161002

S205-161002-Nut-Hex

103

31E3-3065

31E3-3065-Block

11

31E4-1042

31E4-1042-Pipe Assy

110

S631-012001

S631-012001-O-Ring

15

31E4-1058

31E4-1058-Pipe Assy

2

31E4-0032

31E4-0032-Turning Joint

27

31E4-2010

31E4-2010-Hose Assy

32

31E4-2140

31E4-2140-Hose Assy

34

31E4-2077

31E4-2077-Hose Assy

36

31E3-2018

31E3-2018-Hose Assy

42

31E4-2091

31E4-2091-Hose Assy

49

31E4-2117

31E4-2117-Hose Assy

62

P010-110002

P010-110002-Connector

63

P010-110012

P010-110012-Connector

66

P010-210005

P010-210005-Connector

72

P020-110001

P020-110001-Elbow-90

73

P010-110003

P010-110003-Connector

74

P220-110102

P220-110102-Plug

76

P010-110004

P010-110004-Connector

79

CO0423A

CO0423A-O-Ring

80

S631-011001

S631-011001-O-Ring

81

S631-014001

S631-014001-O-Ring

82

S631-018001

S631-018001-O-Ring

84

P392-220000

P392-220000-Washer-Copper

87

P010-220010

P010-220010-Connector

88

P173-160104

P173-160104-Flange-Split

9

31E4-1040

31E4-1040-Pipe Assy

91

S017-100402

S017-100402-Bolt-Hex

95

S017-160454

S017-160454-Bolt-Hex

96

S019-120356

S019-120356-Bolt-Socket

97

S109-100306

S109-100306-Bolt-Socket

99

S411-100002

S411-100002-Washer-Spring
