Запчасти Hyundai R200W2 MAIN PUMP

293G412-9N29

293G412-9N29-Pump

*

293G4127-9N09

293G4127-9N09-Pump

1

3803830583-1

3803830583-1-. Gear Pump

11

2943800463

2943800463-. Plate-Set

12

2953801765

2953801765-. Bushing

13

2953801769

2953801769-. Spring-Cylinder

14

2953801764

2953801764-. Spacer

15

68710-00-211

68710-00-211-. Plate-Shoe

17

P1R2025125

P1R2025125-. Bushing

18

2933800809

2933800809-. Support-Sp

19

2943800464

2943800464-. Cover-Front

2

2933800774

2933800774-. Shaft-Drive(F)

20

2933800828

2933800828-. Cover-Rear

21

2923800807

2923800807-. Casing-Pump

22

2923801021

2923801021-. Block-Valve

23

3890R-313N

3890R-313N-. Plate-Valve-Rh

24

3890L-314N

3890L-314N-. Plate-Valve-Lh

25

2933800928

2933800928-. Casing-Valve

26

2953801767

2953801767-. Screw

27

OSBM820

OSBM820-. Screw-Hex Soc Hd

28

OSBM655

OSBM655-. Screw

29

OSBM840

OSBM840-. Bolt

3

2933800883

2933800883-. Shaft-Drive(R)

30

OVP14

OVP14-. Plug

31

OVP34

OVP34-. Plug

32

PBP116-2403

PBP116-2403-. Plug

34

2943800462

2943800462-. Piston-Servo

35

2953801761

2953801761-. Stopper(L)

36

2953801762

2953801762-. Stopper(S)

4

2953801763

2953801763-. Coupling-Spline

40

ODW732

ODW732-. Ball-Steel

42

OORBG35

OORBG35-. O-Ring

43

OORBG95

OORBG95-. O-Ring

44

OORBG145

OORBG145-. O-Ring

45

OORBP8

OORBP8-. O-Ring

46

OORBP11

OORBP11-. O-Ring

47

OORBP14

OORBP14-. O-Ring

48

OORBP24

OORBP24-. O-Ring

49

OORBP18

OORBP18-. O-Ring

5

PNUP308K

PNUP308K-. Bearing-Roller

50

PTCV40V

PTCV40V-. Seal-Oil

51

OT2BP18

OT2BP18-. Ring-Back Up

52

OT2BG35

OT2BG35-. Ring-Back Up

53

ORNM16

ORNM16-. Nut

54

ORNM20

ORNM20-. Nut

55

OSR40

OSR40-. Ring-Snap

56

PJR812

PJR812-. Pin-Valve Plate

57

OSPV614

OSPV614-. Pin-Spring

58

OEBM10

OEBM10-. Bolt-Eye

59

PSSSM1630

PSSSM1630-. Screw-Set

6

PRNA6906

PRNA6906-. Bearing-Needle

60

2953801768

2953801768-. Screw-Set

61

PNPA-2550A

PNPA-2550A-. Plate-Name

62

OSK2548

OSK2548-. Pin

63

V8701302622

V8701302622-. Proportional Valve

7

38800-127

38800-127-. Spacer-Bearing

8

2933800787

2933800787-. Block-Cylinder

N10

38900-152

38900-152-. Shoe

N16

2933800813

2933800813-. Plate-Swash

N33

2943800517

2943800517-. Pin-Tilting

N37

2953802029

2953802029-. Seat

N38

2953802030

2953802030-. Stopper(1)

N39

2953802043

2953802043-. Stopper(2)

N41

2953802202

2953802202-. Pin-Feed Back

N9

38901-151

38901-151-. Piston
