Запчасти Hyundai R130W COWLING

71EA-22000

71EA-22000-Hood Wa-Mcv

71EA-22000

71EA-22000-Hood Wa-Mcv

10

71E6-2310

71E6-2310-Support-Mcv Hood,Rr

11

71EA-23200

71EA-23200-Support-Tp Mcv Hood

13

71EA-23500

71EA-23500-Support-Pump Hood

14

71EA-24100

71EA-24100-Screen Assy

14-1

71EA-24110

71EA-24110-. Screen Plate

14-2

71E6-2403

71E6-2403-. Sponge

14-3

71EA-24140

71EA-24140-. Sponge

14-4

71EA-24130

71EA-24130-. Sponge

14-5

71E1-5218

71E1-5218-. Pin-Cap & Galv

15

E127-2099

E127-2099-Bracket-Side Cover

16

E271-2100

E271-2100-Bracket-Cover Lock

18

E171-2014

E171-2014-Stay

2

71EA-21700

71EA-21700-Side Cover Assy-Lh,Fr

2-1

71EA-21710

71EA-21710-. Side Cover Wa-Lh

2-3

71E6-2165

71E6-2165-. Sponge

20

E171-2053

E171-2053-Shim

22

E271-2166

E271-2166-Shim

23

71E3-2103

71E3-2103-Shim

24

S017-120252

S017-120252-Bolt-Hex

26

S411-120002

S411-120002-Washer-Spring

28

S403-122002

S403-122002-Washer-Plain

3-1

71EA-21510

71EA-21510-. Side Cover Wa-Lh

3-2

71EA-21540

71EA-21540-. Sponge

3-3

71E6-2171

71E6-2171-. Sponge

31

S461-250207

S461-250207-Pin-Cotter

32

S403-102002

S403-102002-Washer-Plain

33

71E6-2425

71E6-2425-Sponge

34

S207-121002

S207-121002-Nut-Hex

4

71EA-21600

71EA-21600-Side Cover Assy-Rh

4-1

71EA-21610

71EA-21610-. Side Cover Wa-Rh

4-2

71E6-2153

71E6-2153-. Sponge

4-3

71EA-21630

71EA-21630-. Sponge

4-4

71E3-2105

71E3-2105-. Rubber Pad

4-4

71E3-2105

71E3-2105-. Rubber Pad

4-4

71E3-2105

71E3-2105-. Rubber Pad

6

71EA-22200

71EA-22200-Hood Wa-Swing Motor

7

71EA-22300

71EA-22300-Hood-Radiator

8

71EA-22500

71EA-22500-Hood-Pump

9

71EA-23700

71EA-23700-Support-Fr Mcv Hood

N12

71EA-23101

71EA-23101-Support-Lh

N2-2

71EA-21720

71EA-21720-. Sponge

N3

71EA-21500

71EA-21500-Side Cover Assy-Lh,Rr

N3A

SC-037

SC-037-Side Cover Assy-Lh,Rr

N4A

SC-034

SC-034-Side Cover Assy-Rh,Rr
