Запчасти Hyundai R130W ATT HYD PIPING(CYL, 2PCS BOOM, #0194-)

1

31EA-01110

31EA-01110-Cylinder-Boom,Lh

10

31EA-01791

31EA-01791-Pipe Assy

11

31EA-01802

31EA-01802-Pipe Assy

12

31EA-01812

31EA-01812-Pipe Assy

13

31EA-01821

31EA-01821-Pipe Assy

14

31EA-01831

31EA-01831-Pipe Assy

2

31EA-01120

31EA-01120-Cylinder-Boom,Rh

20

P600-086033

P600-086033-Hose Assy-Thd

21

P601-126018

P601-126018-Hose Assy-Thd

22

P601-086018

P601-086018-Hose Assy-Thd

23

P601-086020

P601-086020-Hose Assy-Thd

24

P601-086027

P601-086027-Hose Assy-Thd

25

P601-086013

P601-086013-Hose Assy-Thd

26

P601-086022

P601-086022-Hose Assy-Thd

27

P600-126039

P600-126039-Hose Assy-Thd

28

P600-086019

P600-086019-Hose Assy-Thd

33

31E4-3034

31E4-3034-Connector

34

31EA-01930

31EA-01930-Clamp Hose

35

P010-110004

P010-110004-Connector

44

E131-0277

E131-0277-Pipe-Spacer

45

31E3-3061

31E3-3061-Clamp Pipe-F

46

31EA-01910

31EA-01910-Clamp

5

31EA-01740

31EA-01740-Cylinder-Adj,Lh

52

S017-160602

S017-160602-Bolt-Hex

54

S015-081002

S015-081002-Bolt-Hex

57

S411-160002

S411-160002-Washer-Spring

6

31EA-01750

31EA-01750-Cylinder-Adj,Rh

60

S411-080002

S411-080002-Washer-Spring

61

S275-080002

S275-080002-Nut-Self Locking

63

S690-022100

S690-022100-Grommet

64

S691-034100

S691-034100-Grommet

65

31EA-01900

31EA-01900-Plate

7

31EA-01761

31EA-01761-Pipe Assy

8

31EA-01771

31EA-01771-Pipe Assy

9

31EA-01781

31EA-01781-Pipe Assy
