Запчасти Hyundai R130W ATT HYD PIPING(PIN TYPE, 2PCS BOOM)

10

P600-126018

P600-126018-Hose Assy-Thd

11

P601-086022

P601-086022-Hose Assy-Thd

14

31EA-01130

31EA-01130-Pipe Assy

15

31EA-01140

31EA-01140-Pipe Assy

16

31EA-01150

31EA-01150-Pipe Assy

17

31EA-01160

31EA-01160-Pipe Assy

18

31EA-01170

31EA-01170-Pipe Assy

19

31EA-01180

31EA-01180-Pipe Assy

25

P010-110004

P010-110004-Connector

26

P010-110005

P010-110005-Connector

32

31EA-01330

31EA-01330-Clamp-Hose

33

31E3-3061

31E3-3061-Clamp Pipe-F

36

E131-0277

E131-0277-Pipe-Spacer

40

S017-100604

S017-100604-Bolt-Hex

41

S017-160604

S017-160604-Bolt-Hex

42

S275-100002

S275-100002-Nut-Self Locking

43

S403-102002

S403-102002-Washer-Plain

45

S411-160002

S411-160002-Washer-Spring

5

P601-126018

P601-126018-Hose Assy-Thd

50

31E3-3132

31E3-3132-Clamp Pipe-M

51

S017-100402

S017-100402-Bolt-Hex

52

S411-100002

S411-100002-Washer-Spring

53

P601-086020

P601-086020-Hose Assy-Thd

6

P601-086018

P601-086018-Hose Assy-Thd

7

P601-086016

P601-086016-Hose Assy-Thd

8

P600-126025

P600-126025-Hose Assy-Thd

9

P600-086025

P600-086025-Hose Assy-Thd
