Запчасти Hyundai R130W 2 PIECE BOOM (CYL TYPE)

1

62E3-13000

62E3-13000-Boom Assy-2pcs Cyl 1

1-1

62E3-13011

62E3-13011-. Boom Wa-2pcs Cyl 1

1-2

62E3-12400

62E3-12400-. Bushing

1-3

61E3-1121

61E3-1121-. Bushing

10

62E3-12350

62E3-12350-Washer-Hardened

11

61E3-1050

61E3-1050-Stopper-Pin

12

61E3-1190

61E3-1190-Pin-Stop

13

61E3-1191

61E3-1191-Spring-Lock

14

62E3-12380

62E3-12380-Nut-Slotted

15

S461-800902

S461-800902-Pin-Split

16

S390-065120

S390-065120-Shim-Round(0.5§®)

17

S391-065120

S391-065120-Shim-Round(1.0§®)

18

S392-065120

S392-065120-Shim-Round(2.0§®)

19

S390-070120

S390-070120-Shim-Round(0.5§®)

2

62E3-13500

62E3-13500-Boom Assy-2pcs Cyl 2

2-1

62E3-13511

62E3-13511-. Boom Wa-2pcs Cyl 2

2-2

61E3-1122

61E3-1122-. Bushing

2-3

S700-070206

S700-070206-. Seal-Dust

2-3

S700-070206

S700-070206-. Seal-Dust

20

S391-070120

S391-070120-Shim-Round

21

S392-070120

S392-070120-Shim-Round

3

61E3-1101

61E3-1101-Pin-Attach

4

61E3-1102

61E3-1102-Pin-Attach

5

61E3-1103

61E3-1103-Pin Assy

6

61E3-1104

61E3-1104-Pin Assy

7

61E3-1105

61E3-1105-Pin Assy

8

62E3-13310

62E3-13310-Pin

9

62E3-13320

62E3-13320-Pin
