Запчасти Hyundai R130W 2 PIECE BOOM (PIN TYPE)

1

62E3-12000

62E3-12000-Boom Assy (1st)

1-1

62E3-12010

62E3-12010-. Boom Wa (1st)

1-2

61E3-1121

61E3-1121-. Bushing

1-3

62E3-1240

62E3-1240-. Bushing

1-5

S700-070206

S700-070206-. Seal-Dust

10

62E3-12360

62E3-12360-Hardened Washer

11

61E3-1050

61E3-1050-Stopper-Pin

12

62E3-12380

62E3-12380-Nut-Slotted

13

62E3-12390

62E3-12390-Nut-Slotted

14

61E3-1190

61E3-1190-Pin-Stop

15

61E3-1191

61E3-1191-Spring-Lock

16

S461-800902

S461-800902-Pin-Split

17

S390-065120

S390-065120-Shim-Round(0.5§®)

18

S391-065120

S391-065120-Shim-Round(1.0§®)

19

S392-065120

S392-065120-Shim-Round(2.0§®)

2

62E3-12500

62E3-12500-Boom Assy (2nd)

2-1

62E3-12510

62E3-12510-. Boom Wa (2nd)

2-2

62E3-12410

62E3-12410-. Bushing

2-2

62E3-12410

62E3-12410-. Bushing

20

S390-070120

S390-070120-Shim-Round(0.5§®)

21

S391-070120

S391-070120-Shim-Round

22

S392-070120

S392-070120-Shim-Round

23

62E3-12490

62E3-12490-Plug

3

61E3-1101

61E3-1101-Pin-Attach

4

61E3-1102

61E3-1102-Pin-Attach

5

62E3-12310

62E3-12310-Pin

6

61E3-1105

61E3-1105-Pin Assy

7

62E3-12320

62E3-12320-Pin

8

61E3-1104

61E3-1104-Pin Assy

9

62E3-12350

62E3-12350-Washer-Hardened
