Запчасти Hyundai R130W DOZER BLADE

51EA-31521

51EA-31521-Hook Wa-Rh

51EA-31511

51EA-31511-Hook Wa-Lh

1

51EA-3200

51EA-3200-Blade Assy

1-1

51EA-3100

51EA-3100-. Blade Wa

1-10

51E3-3156

51E3-3156-. Pin-Blade Link

1-11

51E3-3164

51E3-3164-. Plate-Lock

1-12

61E3-2050

61E3-2050-. Shim (0.5t)

1-13

61E3-2051

61E3-2051-. Shim (1.0t)

1-14

61E3-2052

61E3-2052-. Shim (2.0t)

1-15

S651-810002

S651-810002-. Nipple-Grease

1-16

S017-120252

S017-120252-. Bolt-Hex

1-17

S017-120502

S017-120502-. Bolt-Hex

1-18

S411-120002

S411-120002-. Washer-Spring

1-2

51EA-31211

51EA-31211-. Bracket Wa-Lh

1-3

51EA-31221

51EA-31221-. Bracket Wa-Rh

1-4

51EA-3131

51EA-3131-. Link(A) Assy

1-5

51EA-3141

51EA-3141-. Link(B)-Lh

1-6

51EA-3142

51EA-3142-. Link(B)-Rh

1-7

51E3-3143

51E3-3143-. Washer-Lock

1-8

51E3-3154

51E3-3154-. Pin(A)-Blade

1-9

51E3-3155

51E3-3155-. Pin(B)-Blade

10

61E3-2054

61E3-2054-Shim(1.0§®)

11

61E3-2055

61E3-2055-Shim(2.0§®)

12

S651-810002

S651-810002-Nipple-Grease

13

S017-120252

S017-120252-Bolt-Hex

14

S017-120502

S017-120502-Bolt-Hex

15

S018-240502

S018-240502-Bolt-Hex

16

S411-120002

S411-120002-Washer-Spring

17

S411-240002

S411-240002-Washer-Spring

2

51EA-3151

51EA-3151-Hook Wa-Lh

3

51EA-3152

51EA-3152-Hook Wa-Rh

4

51E3-3143

51E3-3143-Washer-Lock

5

51E3-3151

51E3-3151-Pin-B/Cyl Head

6

51E3-3152

51E3-3152-Pin-B/Cyl Rod,Lh

7

51E3-3153

51E3-3153-Pin-B/Cyl Rod,Rh

8

51E3-3164

51E3-3164-Plate-Lock

9

61E3-2053

61E3-2053-Shim(0.5§®)
