Запчасти Hyundai R120W HEATER ASSY

S520-015000

S520-015000-Clamp

21E3-4008

21E3-4008-Control Lever-Heater

21E3-4008

21E3-4008-Control Lever-Heater

1

21E3-4004

21E3-4004-Heater Assy

10

S161-080152

S161-080152-Screw

11

E127-3136

E127-3136-Valve-Cut Off

13

S161-060152

S161-060152-Screw

14

S411-060002

S411-060002-Washer-Spring

15

S551-050203

S551-050203-Clamp-Band

2

S015-080202

S015-080202-Bolt-Hex

3

S411-080002

S411-080002-Washer-Spring

4

E127-3036

E127-3036-Adapter

5

21E3-4012

21E3-4012-Hose-Inlet

6

21E3-4011

21E3-4011-Hose-Outlet

7

21E3-4010

21E3-4010-Hose-Outlet

8

S571-150002

S571-150002-Clamp-Hose Wire Type

9

21E3-4009

21E3-4009-Valve-Adjustable
