Запчасти Hyundai R120W ENGINE CONTROL CABLE

1

E111-4603

E111-4603-Lever Assy

10

81E3-0010

81E3-0010-Roller-Pedal

11

81E3-0011

81E3-0011-Du-Bushing

12

81E3-0012

81E3-0012-Du-Bushing

13

81E3-0009

81E3-0009-Spring

14

S461-200162

S461-200162-Pin-Split

15

S491-080302

S491-080302-Pin-Clevis

16

S017-100302

S017-100302-Bolt-Hex

17

S411-100002

S411-100002-Washer-Spring

18

S472-300203

S472-300203-Pin-Clevis

19

S492-100402

S492-100402-Pin-Clevis

2

71E3-0037

71E3-0037-Bracket-Accel

20

S017-100802

S017-100802-Bolt-Hex

21

S207-101002

S207-101002-Nut-Hex

22

S015-080252

S015-080252-Bolt-Hex

23

S411-080002

S411-080002-Washer-Spring

24

S205-081002

S205-081002-Nut-Hex

25

S105-080162

S105-080162-Bolt

26

S402-082002

S402-082002-Washer-Plain

27

S015-080502

S015-080502-Bolt-Hex

3

71E3-0036

71E3-0036-Lever-Accel(2)

4

71E3-0035

71E3-0035-Lever-Accel(1)

5

71E3-0039

71E3-0039-Du-Bushing

6

71E3-0034

71E3-0034-Bracket-Cable

7

71E3-0018

71E3-0018-Cable (1)

8

81E3-0005

81E3-0005-Pedal-Accel

9

81E3-0006

81E3-0006-Support-Pedal
