Запчасти Hyundai R420 FUEL INJECTION PUMP(2/2)

ND949013-8230

ND949013-8230-.. Washer(0.9)

ND949013-8220

ND949013-8220-.. Washer(0.6)

*-1

ND190800-2460

ND190800-2460-. Governor Assy

1

ND190890-0140

ND190890-0140-.. Cover

10

ND090892-0080

ND090892-0080-.. Bushing

11

ND949140-5760

ND949140-5760-.. O-Ring

12

ND949071-0090

ND949071-0090-.. Washer-Snap

13

ND949047-1760

ND949047-1760-.. Bolt

14

ND949047-1750

ND949047-1750-.. Bolt

15

ND949150-2690

ND949150-2690-.. Seal-Oil

16

ND091071-1420

ND091071-1420-.. Lever-Adjust

17

ND091071-4150

ND091071-4150-.. Lever-Adjust

18

ND949047-1190

ND949047-1190-.. Bolt

19

ND091094-0060

ND091094-0060-.. Cap

2

ND091031-0150

ND091031-0150-.. Nut-Cap

20

ND949047-1790

ND949047-1790-.. Bolt

21

ND091051-0480

ND091051-0480-.. Plate

22

ND91418-06141

ND91418-06141-.. Bolt

23

ND91418-06161

ND91418-06161-.. Bolt

24

ND090241-0010

ND090241-0010-.. Washer

25

ND091031-0030

ND091031-0030-.. Nut-Cap

26

ND949062-1650

ND949062-1650-.. Packing

27

ND949130-0030

ND949130-0030-.. Key-Woodruff

28

ND090944-0440

ND090944-0440-.. Bushing

29

ND949013-8210

ND949013-8210-.. Washer(0.3)

3

ND091006-0150

ND091006-0150-.. Screw-Adjust

30

ND949050-3390

ND949050-3390-.. Nut

31

ND949018-1020

ND949018-1020-.. Washer

32

ND949140-5740

ND949140-5740-.. O-Ring

4

ND090944-0310

ND090944-0310-.. Bushing

5

ND090989-0010

ND090989-0010-.. Shaft

6

ND090991-0010

ND090991-0010-.. Plug

7

ND090560-0200

ND090560-0200-.. Capsule-Fuel Stop

8

ND090923-0060

ND090923-0060-.. Nut-Lock

9

ND090880-0120

ND090880-0120-.. Lever-Swivel

N*

6151-73-1210

6151-73-1210-Injection Pump Assy
