Запчасти Hyundai R420 TRAVEL MOTOR 1

*-1

708-8K-00032

708-8K-00032-. Travel Motor Assy

*-11

708-8K-04111

708-8K-04111-.. Case Sub Assy

10

04065-01124

04065-01124-.. Ring

21

04065-08025

04065-08025-.. Ring-Snap

26

708-8K-13311

708-8K-13311-.. Piston Sub Assy

28

708-8K-15160

708-8K-15160-.. O-Ring

30

07000-15230

07000-15230-.. O-Ring

36

708-8K-14161

708-8K-14161-.. Piston

6

04064-07525

04064-07525-.. Ring

7

708-8K-12141

708-8K-12141-.. Seal

8

708-8K-12180

708-8K-12180-.. Case

9

07000-02105

07000-02105-.. O-Ring

N

@

@-Not Individually Supplied

N*

31E7-4101

31E7-4101-T/Motor & R/Gear

N*-12

708-8K-04051

708-8K-04051-.. Cradle Assy

N*-13

708-8K-04041

708-8K-04041-.. Cyl Block

N1

@

@-... Case-Motor

N11

708-8K-13514

708-8K-13514-... Cradle

N12

708-8K-13411

708-8K-13411-... Cam

N13

04020-01638

04020-01638-.. Pin

N14

708-8K-13520

708-8K-13520-.. Bolt

N15

708-8H-13920

708-8H-13920-.. Seal

N16

708-8K-13351

708-8K-13351-.. Guide

N17

708-8K-13361

708-8K-13361-.. Pin

N18

708-8K-13140

708-8K-13140-.. Seat

N19

708-8K-13150

708-8K-13150-.. Spring

N2

@

@-... Plug

N20

708-8J-13130

708-8J-13130-.. Seat

N22

708-8K-12130

708-8K-12130-.. Bearing

N23

708-8K-13111

708-8K-13111-... Cyl Block

N24

708-8K-13121

708-8K-13121-... Plate

N25

708-8K-13341

708-8K-13341-.. Retainer

N27

708-8K-15181

708-8K-15181-.. Piston

N29

708-8K-15170

708-8K-15170-.. Ring

N3

708-8K-12111

708-8K-12111-.. Shaft

N31

07001-05230

07001-05230-.. Ring

N32

708-8K-15151

708-8K-15151-.. Spring

N33

708-8K-15111

708-8K-15111-.. Spacer

N34

708-8K-15131

708-8K-15131-.. Plate

N35

708-8K-15121

708-8K-15121-.. Disk

N37

708-8K-14141

708-8K-14141-.. Piston

N38

708-8K-14151

708-8K-14151-.. Spring

N39

708-8K-14210

708-8K-14210-.. Plug

N4

708-8K-12120

708-8K-12120-.. Bearing

N40

07002-13334

07002-13334-.. O-Ring

N5

708-8K-12161

708-8K-12161-.. Ring
