Запчасти Hyundai R420 CONTROL VALVE 5

*-29

709-90-52302

709-90-52302-. Relief Valve Assy

*-31

709-90-59400

709-90-59400-. Relief Valve Assy

10

709-20-51231

709-20-51231-.. Spring

11

700-90-51350

700-90-51350-.. Sleeve

13

700-90-51190

700-90-51190-.. Nut

14

07002-03034

07002-03034-.. O-Ring

15

709-70-51150

709-70-51150-.. Plug

16

07239-12410

07239-12410-.. Nut

17

07000-02018

07000-02018-.. O-Ring

18

700-93-11320

700-93-11320-.. O-Ring

19

700-93-11330

700-93-11330-.. Ring-Back Up

20

07002-03634

07002-03634-.. O-Ring

22

700-22-11410

700-22-11410-.. O-Ring

23

07002-02434

07002-02434-.. O-Ring

24

700-20-51550

700-20-51550-.. Ring-Snap

25

700-20-51540

700-20-51540-.. Retainer

27

709-70-51210

709-70-51210-.. Spring

28

709-70-51420

709-70-51420-.. Poppet

29

700-20-51620

700-20-51620-.. Spring

3

709-90-51320

709-90-51320-.. Spring

30

700-20-51340

700-20-51340-.. Screw

31

07000-02011

07000-02011-.. O-Ring

4

709-90-51340

709-90-51340-.. Plug

8

700-80-61190

700-80-61190-.. Poppet

N

@

@-Not Individually Supplied

N12

@

@-.. Holder

N21

@

@-.. Sleeve

N21

@

@-.. Sleeve

N26

@

@-.. Valve

N26

@

@-.. Valve

N32

01582-11411

01582-11411-.. Nut

N5

@

@-.. Seat

N6

@

@-.. O-Ring

N7

@

@-.. Ring-Back Up

N9

@

@-.. Retainer
