Запчасти Hyundai R320LC AIR CONDITIONER MOUNTING

S017-100652

S017-100652-Bolt-Hex

S017-100652

S017-100652-Bolt-Hex

1

11E8-36010

11E8-36010-Air Con Assy-R134a

1

11E8-3501

11E8-3501-Air Con Assy-R12

1-1

12E1-3501

12E1-3501-. Cooling Unit

1-1

11EK-35010

11EK-35010-. Cooling Unit Assy

1-1-1

C34063E1

C34063E1-.. Expansion V/V

1-1-1

C3426E0

C3426E0-.. Valve-Expansion

1-10

11EK-35090

11EK-35090-. Joint Assy-Comp

1-10

12E1-3512

12E1-3512-. Joint-Component

1-11

12E1-3513

12E1-3513-. Bracket-R/Dryer

1-11

12E1-3513

12E1-3513-. Bracket-R/Dryer

1-12

12E1-3514

12E1-3514-. Hose-Drain

1-12

12E1-3514

12E1-3514-. Hose-Drain

1-13

12E1-3515

12E1-3515-. O-Ring

1-14

12E1-3516

12E1-3516-. O-Ring

1-15

12E1-3517

12E1-3517-. O-Ring

1-16

12E1-3518

12E1-3518-. Switch Assy

1-16

12E1-3518

12E1-3518-. Switch Assy

1-2

12E1-3502

12E1-3502-. Compressor

1-2

11EK-35020

11EK-35020-. Compressor Assy

1-3

12E1-3503

12E1-3503-. Condenser Assy

1-3

11EK-35030

11EK-35030-. Condenser Assy

1-4

11EK-35040

11EK-35040-. Receiver Dryer

1-4

12E1-3504

12E1-3504-. Receiver Dryer

1-5

11E9-37020

11E9-37020-. Hose Assy-Discharge

1-5

71E7-0169

71E7-0169-. Hose-Discharge

1-6

11E2-36020

11E2-36020-. Liquid Hose Assy(A)

1-6

12E2-3501

12E2-3501-. Hose Asy-Liquid(A)

1-7

11E2-36030

11E2-36030-. Liquid Hose Assy(B)

1-7

12E2-3502

12E2-3502-. Hose-Liquid(B)

1-8

11E2-36040

11E2-36040-. Suction Hose Assy

1-8

12E2-3503

12E2-3503-. Hose-Suction

1-9

12E1-3511

12E1-3511-. Adjuster

1-9

12E1-3511

12E1-3511-. Adjuster

10

S015-080352

S015-080352-Bolt-Hex

11

S015-080202

S015-080202-Bolt-Hex

12

S015-050152

S015-050152-Bolt-Hex

13

S411-050002

S411-050002-Washer-Spring

14

S015-060152

S015-060152-Bolt-Hex

15

S205-061002

S205-061002-Nut-Hex

16

S411-060002

S411-060002-Washer-Spring

17

S542-220002

S542-220002-Clamp-Tube

18

E127-3153

E127-3153-Clamp-Hose

19

S152-050202

S152-050202-Screw-Tapping

19

S152-050202

S152-050202-Screw-Tapping

2

12E2-3504

12E2-3504-Bracket-Comp.Mtg

21

S015-060202

S015-060202-Bolt-Hex

3

71L1-1011

71L1-1011-V-Belt

4

S017-100252

S017-100252-Bolt-Hex

5

S411-100002

S411-100002-Washer-Spring

6

S017-100402

S017-100402-Bolt-Hex

7

71L1-1012

71L1-1012-Pin

8

S601-011004

S601-011004-Ring-Retaining

9

S411-080002

S411-080002-Washer-Spring
