Запчасти Hyundai R320LC TRAVEL MOTOR

*

31E5-0003

31E5-0003-Track Motor

*-1

33522-ABB325A

33522-ABB325A-. Travel Motor Unit

*-2

3550BX067

3550BX067-. T/Reduction Gear

022

VZ40103067

VZ40103067-.. Spool-C/Balance

101

3330800106

3330800106-.. Shaft-Drive

102

PNUP2210

PNUP2210-.. Bearing-Roller

103

PNK385227

PNK385227-.. Bearing-Needle

106

371A00AA-106

371A00AA-106-.. Spacer-Bearing

107

OSR50

OSR50-.. Ring-Snap

113

2953801840

2953801840-.. Bushing-Spherical

114

2953801842

2953801842-.. Spring-Cylinder

116

2953801841

2953801841-.. Spacer

123

2943800488

2943800488-.. Plate-Set

201

3330800109

3330800109-.. Plate-Swash

202

3330800110

3330800110-.. Support

304

3340800109

3340800109-.. Cover-Seal

350

V8807044983

V8807044983-.. Valve-Relief

361

5A250010-3310

5A250010-3310-.. Washer

362

3350800152

3350800152-.. Spring-C/Balance

364

3350800150

3350800150-.. Cover-C/Balance

365

OORBG45

OORBG45-.. O-Ring

366

OSBM1245

OSBM1245-.. Bolt-Socket

401

OSBM1650

OSBM1650-.. Bolt-Socket

402

OSBM16120

OSBM16120-.. Bolt-Socket

435

ORR85

ORR85-.. Ring-Snap

451

PJR1014

PJR1014-.. Pin-2

452

PJR1524

PJR1524-.. Pin-1

461

PBP116-2403

PBP116-2403-.. Plug

464

OVP12

OVP12-.. Plug

471

OORBG75

OORBG75-.. O-Ring

472

PCPP275

PCPP275-.. O-Ring

485

OORBP18

OORBP18-.. O-Ring

491

PTCV48V

PTCV48V-.. Seal-Oil

501

3340800118

3340800118-.. Piston-Tilting

502

3350800266

3350800266-.. Piston-Tilting

503

3350800311

3350800311-.. Stopper

504

3350800160

3350800160-.. Stopper-S

505

3350800148

3350800148-.. Rod-Tilting

506

PSSSM1640

PSSSM1640-.. Screw

507

ONM16C

ONM16C-.. Nut

508

OORBP22A

OORBP22A-.. O-Ring

509

OORBP16

OORBP16-.. O-Ring

510

OT2BP16

OT2BP16-.. Ring-Back Up

511

OORBP10A

OORBP10A-.. O-Ring

512

OT2BP22A

OT2BP22A-.. Ring-Back Up

531

3350800149

3350800149-.. Spool-Tilting

533

3350800154

3350800154-.. Spring-Tilting

541

2953801680

2953801680-.. Seat

542

3350800155

3350800155-.. Stopper

543

ODW732

ODW732-.. Ball-Steel

545

OTRS116A15

OTRS116A15-.. Orifice

546

OTRS116A10

OTRS116A10-.. Orifice

547

OORBP10

OORBP10-.. O-Ring

567

OVP14

OVP14-.. Plug

568

OORBP11

OORBP11-.. O-Ring

571

37DA00AA-668

37DA00AA-668-.. Plug

572

OORBP14

OORBP14-.. O-Ring

702

3330800107

3330800107-.. Piston-Brake

705

3350800153

3350800153-.. Spring-Brake

707

3350800174

3350800174-.. Ring 252-Piston

708

3350800151

3350800151-.. Ring 278-Piston

709

PJR1540

PJR1540-.. Pin-Center

710

34750-00-367

34750-00-367-.. Guide-Spring

711

37KB00AD-368

37KB00AD-368-.. Spool

712

34750-00-369

34750-00-369-.. Bushing

713

34750-00-370

34750-00-370-.. Spring

714

OR038

OR038-.. Plug

741

3350800147

3350800147-.. Plate-Separator

742

3340800110

3340800110-.. Plate-Friction

801

PNPA-2550A

PNPA-2550A-.. Plate-Name

802

OSK2548

OSK2548-.. Pin

A

371A00AA-12

371A00AA-12-(121,122)

B

33522-00-14

33522-00-14-(111,131)

D

33522-01-20

33522-01-20-(303,451)

E

3350800317

3350800317-Seal Kit

N111

3330800108

3330800108-.. Block-Cylinder

N121

371A00AA-121

371A00AA-121-.. Piston

N122

371A00AA-122

371A00AA-122-.. Shoe

N131

3330800114

3330800114-.. Plate-Valve

N272

3320800234

3320800234-.. Casing-A

N303

3320800184

3320800184-.. Casing-Valve

NC

3350800316

3350800316-Casing Sub Assy
