Запчасти Hyundai R290LC REMOTE CONTROL LEVER(RH)

*

E131-0130

E131-0130-Rcv Lever

1

5DT01X05-101

5DT01X05-101-. Casing

10

5DT01X00-211

5DT01X00-211-. Plug

11

5DT61X06-212

5DT61X06-212-. Rod-Push

15

5DT01X01-216

5DT01X01-216-. Seat-Spring

16

5DT01X00-217

5DT01X00-217-. Washer 2

17

5DT01X16-221

5DT01X16-221-. Spring

18

5DT01X00-241

5DT01X00-241-. Pin-Spring

19

5DT61X00-301

5DT61X00-301-. Joint

2

5DT01X02-111

5DT01X02-111-. Plate-Port

20

5DT61X01A-302

5DT61X01A-302-. Plate

21

5DT61X20A-312

5DT61X20A-312-. Nut-Adjust

22

ORNM14C

ORNM14C-. Nut-Lock

23

5DT61X00D323

5DT61X00D323-. Bar-Handle

24

5DT61X00-401

5DT61X00-401-. Handle

25

5DT61X30-402

5DT61X30-402-. Cap-Handle

26

OPSM410

OPSM410-. Screw 1

28

OWM4S

OWM4S-. Washer

29

OPSM430

OPSM430-. Screw 2

30

OPNM4C

OPNM4C-. Nut

30

OPNM4C

OPNM4C-. Nut

31

OPSM58

OPSM58-. Screw 3

32

5DT61X00-451

5DT61X00-451-. Roller

33

5DT61X00-452

5DT61X00-452-. Lever

34

5DT61X00-453

5DT61X00-453-. Seat 1-Switch

35

5DT61X00-454

5DT61X00-454-. Seat 2-Switch

36

5DT61X00-455

5DT61X00-455-. Switch

37

5DT61X00A-456

5DT61X00A-456-. Cord

38

5DT61X20-457

5DT61X20-457-. Bushing

39

5DT61X20A458

5DT61X20A458-. Tube

40

5DT6A102-459

5DT6A102-459-. Terminal

41

5DT61X40-501

5DT61X40-501-. Bellows

5

OSBM830

OSBM830-. Bolt-Socket

6

OSPV510

OSPV510-. Pin-Spring

7

5DT01X00-131

5DT01X00-131-. Bushing

8

5DT61X20-151

5DT61X20-151-. Plate

9

5DT01X00-201

5DT01X00-201-. Spool

K12

5DT61X20-213

5DT61X20-213-. Seal

K13

OORBP20

OORBP20-. O-Ring

K3

5DT01X01-121

5DT01X01-121-. Washer-Seal

K4

5DT01X00-122

5DT01X00-122-. O-Ring

N

@

@-Not Individually Supplied

N14

5DT01X00-215

5DT01X00-215-. Washer 1
