Запчасти Hyundai R290LC REMOTE CONTROL LEVER(LH)

*

31E9-0040

31E9-0040-Rcv Lever-Lh

1

5DT01X05-101

5DT01X05-101-. Casing

10

5DT01X00-211

5DT01X00-211-. Plug

11

5DT01X04-212

5DT01X04-212-. Rod-Push

12

5DT61X20-213

5DT61X20-213-. Seal

13

OORBP20

OORBP20-. O-Ring

15

5DT01X01-216

5DT01X01-216-. Seat-Spring

16

5DT01X00-217

5DT01X00-217-. Washer 2

17

5DT01X22-221

5DT01X22-221-. Spring

18

5DT01X22-241

5DT01X22-241-. Spring

19

5DT01X01-291

5DT01X01-291-. Seat

2

5DT01X12-111

5DT01X12-111-. Plate-Port

20

ODW516

ODW516-. Ball-Steel

21

VZ50106139-01

VZ50106139-01-. Plug

22

OORBP10

OORBP10-. O-Ring

23

5DT61X00-301

5DT61X00-301-. Joint

24

5DT61X01A-302

5DT61X01A-302-. Plate

25

5DT61X20A-312

5DT61X20A-312-. Nut-Adjust

26

5DT61X00-315

5DT61X00-315-. Nut-Lock

27

5DT61X00D323

5DT61X00D323-. Bar-Handle

28

5DT61X00-401

5DT61X00-401-. Handle

29

5DT61X30-402

5DT61X30-402-. Cap-Handle

3

5DT01X01-121

5DT01X01-121-. Washer-Seal

30

VZ50106114-01

VZ50106114-01-. Screw(1)

32

VZ50107134-01

VZ50107134-01-. Washer

33

VZ50106114-02

VZ50106114-02-. Screw(2)

34

VZ50106277-01

VZ50106277-01-. Nut

34

VZ50106277-01

VZ50106277-01-. Nut

35

VZ50106114-03

VZ50106114-03-. Screw(3)

36

5DT61X00-451

5DT61X00-451-. Roller

37

5DT61X00-452

5DT61X00-452-. Lever

38

5DT61X00-453

5DT61X00-453-. Seat 1-Switch

39

5DT61X00-454

5DT61X00-454-. Seat 2-Switch

4

5DT01X00-122

5DT01X00-122-. O-Ring

40

5DT61X00-455

5DT61X00-455-. Switch

41

5DT61X00A-456

5DT61X00A-456-. Cord

42

5DT61X20-457

5DT61X20-457-. Bushing

43

5DT61X20AD458

5DT61X20AD458-. Tube

44

5DT6A102-459

5DT6A102-459-. Terminal

47

5DT61X40-501

5DT61X40-501-. Bellows

5

OSBM860

OSBM860-. Screw

6

OSPV510

OSPV510-. Pin-Spring

7

5DT01X00-131

5DT01X00-131-. Bushing

8

5DT61X20-151

5DT61X20-151-. Plate

9

5DT01X00-201

5DT01X00-201-. Spool

N

@

@-

N14

5DT01X00-215

5DT01X00-215-. Washer 1

N45

VZ50104951

VZ50104951-. Cap-Insulaton

N46

VZ50104952-1

VZ50104952-1-. Tube-Rubber
