Запчасти Hyundai R280LC TRAVEL HYDRAULIC PIPING(STD)

31E1-0001

31E1-0001-Turning Joint

E231-0079

E231-0079-Pipe

1

E131-0612

E131-0612-Turning Joint

10

E131-0154

E131-0154-Hose Assy

11

E131-0286

E131-0286-Hose Assy

12

E231-0093

E231-0093-Pipe Assy

13

E231-0095

E231-0095-Pipe Assy

14

E231-0097

E231-0097-Pipe Assy

15

E231-0099

E231-0099-Pipe Assy

16

E231-0120

E231-0120-Tee

17

E231-0123

E231-0123-Clamp Pipe-C

18

E231-0187

E231-0187-Hose Assy

19

S107-100602

S107-100602-Bolt-Socket

2

P173-160104

P173-160104-Flange-Split

20

S107-120302

S107-120302-Bolt-Socket

21

S107-100302

S107-100302-Bolt-Socket

22

S205-161004

S205-161004-Nut-Hex

23

S411-100004

S411-100004-Washer-Spring

24

S411-160004

S411-160004-Washer-Spring

25

S551-035146

S551-035146-Clamp-Band

26

S631-011001

S631-011001-O-Ring

27

S631-018001

S631-018001-O-Ring

28

CO0423A

CO0423A-O-Ring

3

E131-0506

E131-0506-Hose Assy

30

S017-160454

S017-160454-Bolt-Hex

4

E131-0507

E131-0507-Hose Assy

6

E131-0038

E131-0038-Tee

7

P010-110002

P010-110002-Connector

8

P010-110004

P010-110004-Connector

9

E131-0156

E131-0156-Hose Assy
