Запчасти Hyundai R200LC COUNTER BLANCE VALVE(ONE SPEED MOTOR)

*-3

A2FE63-MHB20

A2FE63-MHB20-. Counter Balance V/V

1

694494

694494-.. Housing

10

117640

117640-.. Screw

11

417037

417037-.. Valve-Check

12

012297

012297-.. Plug-Screw

13

690823

690823-.. Plug-Screw

14

014139

014139-.. Spring

15

004623

004623-.. Ring-Sealing

16

001053

001053-.. Circlip

17

002342

002342-.. O-Ring

18

008478

008478-.. O-Ring

19

008975

008975-.. O-Ring

2

694492

694492-.. Cover

20

009846

009846-.. O-Ring

21

009505

009505-.. O-Ring

22

003268

003268-.. Screw-Socket

23

003262

003262-.. Screw-Socket

24

009230

009230-.. Screw-Socket

25

694585

694585-.. Ring-Back Up

26

694584

694584-.. Ring-Back Up

3

694491

694491-.. Cover

4

322300

322300-.. Piston

5

184335

184335-.. Retainer-Spring

6

004866

004866-.. Ball-Steel

7

009098

009098-.. O-Ring

8

013709

013709-.. Ring-Back Up

9

172196

172196-.. Screw
