Запчасти Hyundai R200LC EXTENSION ARM(1.5M)

1

64E1-2102

64E1-2102-Extension Arm Assy

1-1

64E1-2100

64E1-2100-. Extension Arm Wa

1-2

64E1-2162

64E1-2162-. Bushing

1-3

E161-2061

E161-2061-. Bushing

1-6

S652-810002

S652-810002-. Nipple-Grease

10

S390-070130

S390-070130-Shim-Round(0.5t)

11

S017-161302

S017-161302-Bolt-Hex

12

S205-161002

S205-161002-Nut-Hex

13

S321-070100

S321-070100-Stopper-Pin

2

64E1-2103

64E1-2103-Extension Rod Assy

2-1

64E1-2101

64E1-2101-. Extension Rod Wa

2-2

64E1-2161

64E1-2161-. Bushing

2-3

E161-2062

E161-2062-. Bushing

2-4

S700-070206

S700-070206-. Dust Seal-Dkiy Type

2-4

S700-070206

S700-070206-. Dust Seal-Dkiy Type

2-5

S651-810002

S651-810002-. Nipple-Grease

2-5

S651-810002

S651-810002-. Nipple-Grease

3

64E1-2150

64E1-2150-Pin

4

E161-1109

E161-1109-Pin

5

64E1-2152

64E1-2152-Control Link Wa-Lh

6

64E1-2153

64E1-2153-Control Link Wa-Rh

7

S391-070120

S391-070120-Shim-Round(1.0t)

8

S392-070120

S392-070120-Shim-Round(2.0t)

9

S392-070130

S392-070130-Shim-Round(2.0t)
