Запчасти Hyundai R130LC UPPER PIPING(NEGATIVE CONTROL TYPE)

1

002031-19150

002031-19150-Hose Assy

10

004012-09000

004012-09000-Plug-Hollow

11

017001-00000

017001-00000-Switch-Toggle

12

018001-00000

018001-00000-Cable

13

002131-19170

002131-19170-Hose Assy

15

002131-19130

002131-19130-Hose Assy

17

007001-0241B

007001-0241B-O-Ring

17

007001-0241B

007001-0241B-O-Ring

19

002111-06060

002111-06060-Hose Assy

19

002111-06060

002111-06060-Hose Assy

2

008006-32000

008006-32000-Port Relief Valve

21

004008-19019

004008-19019-Connector

21

004008-19019

004008-19019-Connector

21

004008-19019

004008-19019-Connector

22

007001-0111B

007001-0111B-O-Ring

23

004008-06006

004008-06006-Connector

23

004008-06006

004008-06006-Connector

23

004008-06006

004008-06006-Connector

24

002111-06200

002111-06200-Hose Assy

25

002111-06100

002111-06100-Hose Assy

25

002111-06100

002111-06100-Hose Assy

26

008001-06024

008001-06024-Control Valve Assy

27

012002-00000

012002-00000-Bracket

28

013001-08030

013001-08030-Bolt-Hex

29

015001-08000

015001-08000-Washer-Spring

30

004003-06006

004003-06006-Elbow-90

31

012005-00000

012005-00000-Bracket-Pedal

32

013002-06020

013002-06020-Bolt-Hex

5

005001-19019

005001-19019-Joint Assy-2 Way

8

013002-10080

013002-10080-Bolt-Hex

9

012003-19000

012003-19000-Bracket

N7

016001-00000

016001-00000-Foot Switch Assy
