Запчасти Hyundai R130LC UPPER PIPING(FLOW CONTROL TYPE)

10

004008-09009

004008-09009-Adapter

11

008002-06024

008002-06024-Solenoid Valve

12

004003-09009

004003-09009-Elbow-90

13

002131-19160

002131-19160-Hose Assy

14

002031-09110

002031-09110-Hose Assy

15

002131-19130

002131-19130-Hose Assy

16

002111-06060

002111-06060-Hose Assy

17

007001-0241B

007001-0241B-O-Ring

17

007001-0241B

007001-0241B-O-Ring

18

004008-19000

004008-19000-Connector

19

002111-06030

002111-06030-Hose Assy

2

002031-19150

002031-19150-Hose Assy

2

002031-19150

002031-19150-Hose Assy

21

004008-19019

004008-19019-Connector

21

004008-19019

004008-19019-Connector

22

007001-0111B

007001-0111B-O-Ring

23

004008-06006

004008-06006-Connector

23

004008-06006

004008-06006-Connector

23

004008-06006

004008-06006-Connector

24

002111-06270

002111-06270-Hose Assy

25

002111-06120

002111-06120-Hose

26

008003-12000

008003-12000-Flow Control Valve

27

004009-12009

004009-12009-Bushing

29

017001-00000

017001-00000-Switch-Toggle

30

018001-00000

018001-00000-Cable

31

020002-06006

020002-06006-Sub Plate

32

013002-06035

013002-06035-Bolt-Hex

33

013002-05045

013002-05045-Bolt-Hex

34

013002-06020

013002-06020-Bolt-Hex

35

012005-00000

012005-00000-Bracket-Pedal

36

004012-09000

004012-09000-Plug-Hollow

37

008006-32000

008006-32000-Port Relief Valve

5

005001-19019

005001-19019-Joint Assy-2 Way

7

012006-06000

012006-06000-Plate

8

013001-08025

013001-08025-Bolt-Hex

9

012003-19019

012003-19019-Bracket

N28

016001-00000

016001-00000-Foot Switch Assy
