Запчасти Hyundai HSL810 FUEL INJECTION VALVE

1

129900-01950

129900-01950-Bracket

10

129100-53110

129100-53110-.. Body-Nozzle Holder

11

129100-53120

129100-53120-.. Pipe-Fuel Return

12

114250-53120

114250-53120-.. Spring-Nozzle

13

114250-53130

114250-53130-. Seat-Nozzle Spring

14

114250-53140

114250-53140-. Plate-Stop

15

114250-53210

114250-53210-. Pin

16

114250-53400

114250-53400-. Pack-Shim

17

114250-53410

114250-53410-.. Shim T0.4

18

114250-53420

114250-53420-.. Shim T0.5

19

114250-53430

114250-53430-.. Shim T0.6

2

26106-100142

26106-100142-Bolt-Plated

20

114250-53440

114250-53440-.. Shim T0.7

21

114250-53450

114250-53450-.. Shim T0.8

22

114250-53460

114250-53460-.. Shim T0.15

23

119305-59120

119305-59120-Retainer

24

119305-59100

119305-59100-. Clamp-Upper

25

119305-59110

119305-59110-. Clamp-Lower

27

129550-59120

129550-59120-Retainer

28

129550-59100

129550-59100-. Clamp-Upper

29

129550-59110

129550-59110-. Clamp-Lower

3

26106-080202

26106-080202-Bolt M 8x 20 Plated

30

129150-59131

129150-59131-. Bolt M4x14-Hex.Sckt.

30

129150-59131

129150-59131-. Bolt M4x14-Hex.Sckt.

32

129902-59810

129902-59810-. Pipe-F/Inject 1

33

129902-59820

129902-59820-. Pipe-F/Inject 2

34

129902-59830

129902-59830-. Pipe-F/Inject 3

35

129902-59840

129902-59840-. Pipe-F/Inject 4

4

729902-53200

729902-53200-Valve-Fuel

5

129902-53050

129902-53050-. Nozzle

8

114250-53080

114250-53080-. Nut-Nozzle Case

9

129100-53100

129100-53100-. Holder Assy-Nozzle

N

@

@-Not Individually Supplied

N31

129902-59800

129902-59800-Pipe-Fuel Injection

N6

129472-53010

129472-53010-.. Valve-Nozzle

N7

129902-53090

129902-53090-.. Body-Nozzle
