Запчасти Hyundai HSL810 FUEL INJECTION PUMP

1

129955-51010

129955-51010-Fuel Injection Pump

10

X1310171000

X1310171000-.. Screw

100

X0265141840

X0265141840-.. Gasket

101

X0296375020

X0296375020-.. O-Ring

102

X0297310120

X0297310120-.. Bolt-Eye

103

X0265101340

X0265101340-.. Gasket

104

129900-52010

129900-52010-. Pump Assy-Fuel Feed

11

X0293406020

X0293406020-.. Gasket

12

X1310341401

X1310341401-.. Plug

13

X1392060400

X1392060400-.. Nut

14

X0296331010

X0296331010-.. O-Ring

15

X1311523420

X1311523420-.. Plunger

16

X1311607920

X1311607920-.. Valve-Delivery

17

X1311123500

X1311123500-.. Spring

18

X1311151600

X1311151600-.. Gasket

19

X1311167600

X1311167600-.. Holder

20

X1311172300

X1311172300-.. Stopper

21

X1311220520

X1311220520-.. Plate

22

X0296320030

X0296320030-.. O-Ring

23

X1312000220

X1312000220-.. Tappet

24

X1312030200

X1312030200-... Pin

25

X1312041000

X1312041000-... Roller

26

X1312050500

X1312050500-... Bushing

27

X1312060200

X1312060200-... Guide

28

X0293110020

X0293110020-.. Shim

29

X0293110030

X0293110030-.. Shim

3

X1310641621

X1310641621-.. Housing-Housing

30

X0293110040

X0293110040-.. Shim

31

X0293110050

X0293110050-.. Shim

32

X0293110060

X0293110060-.. Shim

33

X0293110070

X0293110070-.. Shim

34

X0293110080

X0293110080-.. Shim

35

X0293110090

X0293110090-.. Shim

36

X0293110110

X0293110110-.. Shim

37

X0293110120

X0293110120-.. Shim

38

X0293110130

X0293110130-.. Shim

39

X0293110140

X0293110140-.. Shim

4

X0290406020

X0290406020-.. Stud

40

X0293110270

X0293110270-.. Shim

41

X0293110280

X0293110280-.. Shim

42

X0293110290

X0293110290-.. Shim

43

X0293110310

X0293110310-.. Shim

44

X0293110320

X0293110320-.. Shim

45

X0293110330

X0293110330-.. Shim

46

X0293110340

X0293110340-.. Shim

47

X0293110350

X0293110350-.. Shim

48

X0293110490

X0293110490-.. Shim

49

X0293110500

X0293110500-.. Shim

5

X1340260000

X1340260000-.. Plug

50

X0293110580

X0293110580-.. Shim

51

X0293110590

X0293110590-.. Shim

52

X0293110600

X0293110600-.. Shim

53

X0293110610

X0293110610-.. Shim

54

X0293110620

X0293110620-.. Shim

55

X0293110630

X0293110630-.. Shim

56

X0293110710

X0293110710-.. Shim

57

X1312152500

X1312152500-.. Spring

58

X1312160100

X1312160100-.. Seat-Spring

59

X1312170200

X1312170200-.. Seat-Spring

60

X1312540600

X1312540600-.. Rack-Control

61

X1312260300

X1312260300-.. Screw

62

X1312400100

X1312400100-.. Pinion

63

X1312410100

X1312410100-.. Sleeve-Control

64

X1312420100

X1312420100-.. Screw

65

X1313612700

X1313612700-.. Camshaft

66

X0166402030

X0166402030-.. Bearing

67

X0282020020

X0282020020-.. Bearing

68

X0166302030

X0166302030-.. Bearing

69

X0282017020

X0282017020-.. Bearing

7

X1310022000

X1310022000-.. Cap

7

X1310022000

X1310022000-.. Cap

70

X1313020300

X1313020300-.. Ring

71

X1313021000

X1313021000-.. Ring

72

X0293117010

X0293117010-.. Shim

73

X0293117020

X0293117020-.. Shim

74

X0293117030

X0293117030-.. Shim

75

X0293117040

X0293117040-.. Shim

76

X0293117050

X0293117050-.. Shim

77

X0293117060

X0293117060-.. Shim

78

X0293117070

X0293117070-.. Shim

79

X0293117090

X0293117090-.. Shim

8

X1310286220

X1310286220-.. Cover

80

X0293117210

X0293117210-.. Shim

81

X0293117220

X0293117220-.. Shim

82

X1394170000

X1394170000-.. Shim

83

X0293120220

X0293120220-.. Shim

84

X0293120230

X0293120230-.. Shim

85

X0293120240

X0293120240-.. Shim

86

X0293120250

X0293120250-.. Shim

87

X0293120260

X0293120260-.. Shim

88

X0293120270

X0293120270-.. Shim

89

X0293120290

X0293120290-.. Shim

9

X1310111900

X1310111900-.. Gasket

90

X0293120300

X0293120300-.. Shim

91

X1394200400

X1394200400-.. Shim

92

X0296220190

X0296220190-.. Seal-Oil

93

X1313301800

X1313301800-.. Cover

94

X0200062040

X0200062040-.. Bolt

95

X1313211900

X1313211900-.. Gasket

96

X0131214140

X0131214140-.. Nut

97

X0293214010

X0293214010-.. Spring Washer

98

X0294704030

X0294704030-.. Key-Woodruff

99

X0297314680

X0297314680-.. Bolt-Eye

N

@

@-Not Individually Supplied

N105

129955-61510

129955-61510-. Governor Assy

N2

129955-51110

129955-51110-. Pump-Fo
