Запчасти Hyundai HSL810 CYLINDER BLOCK

1

729902-01560

729902-01560-Block Assy-Cylinder

10

129900-02410

129900-02410-.. Bushing-Camshaft

11

22351-060012

22351-060012-.. Spring Pin 6x12

12

27231-550000

27231-550000-.. Plug

13

23876-030000

23876-030000-.. Plug-Screw

13

23876-030000

23876-030000-.. Plug-Screw

13

23876-030000

23876-030000-.. Plug-Screw

14

27241-300000

27241-300000-.. Plug 30

15

129900-02800

129900-02800-. Bearing Assy-Main

18

129900-02930

129900-02930-. Bearing Assy-Thrust

19

129900-02150

129900-02150-.. Thrust Bearing-Low

20

129900-02160

129900-02160-.. Thrust Bearing-Upp

21

129900-01200

129900-01200-Bolt-Head

22

129902-01330

129902-01330-Gasket-Cyl Head

23

129900-02340

129900-02340-Main Bearing

24

129900-02320

129900-02320-. Bearing-Main

25

129900-02330

129900-02330-. Bearing-Main

26

129900-02940

129900-02940-Bearing-Thrust

27

129900-02360

129900-02360-. Thrust Bearing-Low

28

129900-02370

129900-02370-. Thrust Bearing-Upp

6

171051-01921

171051-01921-.. Plug

7

129900-02020

129900-02020-.. Bolt-Metal Cap

8

129900-02300

129900-02300-.. Cap-Base Metal

9

129900-02310

129900-02310-.. Cap-Metal

N

@

@-Not Individually Supplied

N16

129900-02100

129900-02100-.. Main Bearing-Upp

N17

129900-02110

129900-02110-.. Main Bearing-Low

N2

129902-01000

129902-01000-. Block Comp-Cylinder

N3

129902-01010

129902-01010-.. Block-Cylinder
