Запчасти Hyundai HSL610 TRAVEL MOTOR

*

31S4-00020

31S4-00020-Motor Assy-Travel

1

23488

23488-Plate-Valve

11

201840-001

201840-001-Retainer-Front

12

14253

14253-Bolt

14

8508

8508-Valve Drive

16

21317

21317-Balancing Ring S/A

21

6203

6203-Spring

22

23980-004

23980-004-Valve Housing

23

14409-005

14409-005-Bolt

24

14409-010

14409-010-Bolt

26

230079

230079-Spring

27

8566

8566-Piston

28

8567

8567-Poppet

29

201868-002

201868-002-Plug S/A

3

8507-005

8507-005-Geroler Assy

30

8755

8755-Sleeve

31

9266-006

9266-006-Plug Sub S/A

4

21373-005

21373-005-Drive-Main

5

201839-001

201839-001-Housing-Bearing

7

201837-003

201837-003-Shaft & Bearing Assy

K

61238

61238-Seal Kit(K)

K17

6993

6993-Seal-Inner

K18

6992

6992-Seal-Outer

K19

15062

15062-Seal

K20

15006

15006-O-Ring

K25

8765-010

8765-010-Seal

N15

8497

8497-Valve

NK2

250052-044

250052-044-Seal

NX

@

@-Not Individually Supplied

NX10

6991

6991-Backup Ring

NX13

9039-001

9039-001-Seal-Dust

NX6

9080-001

9080-001-Seal-Shaft Face

NX8

15039

15039-Seal

NX9

9057-013

9057-013-Seal-Shaft

X

61237

61237-Seal Kit(X)
