Запчасти Hyundai HSL600 V/V,ROCKER ARM GROUP

1

15221-1311-0

15221-1311-0-Valve Inlet

10

03410-50808

03410-50808-Screw-Set

11

15221-1435-0

15221-1435-0-Bracket-Rocker Arm

12

15221-9150-0

15221-9150-0-Stud

13

02156-50080

02156-50080-Nut

14

04512-50080

04512-50080-Washer Spring

15

04012-50080

04012-50080-Washer-Plain

16

15221-1442-0

15221-1442-0-Screw Set

17

15221-1443-0

15221-1443-0-Washer-R/Arm Shaft

18

15221-1431-0

15221-1431-0-Spring-Rocker Arm

19

04612-00140

04612-00140-Cir-Clip External

2

15221-1312-0

15221-1312-0-Valve Exhaust

20

15601-1403-0

15601-1403-0-Assy Rocker Arm

21

15221-1411-0

15221-1411-0-Rocker Arm

22

15221-1418-0

15221-1418-0-Bush Rocker Arm

23

15521-1423-0

15521-1423-0-Screw-Adjusting

24

15021-1424-0

15021-1424-0-Nut

3

15221-1324-0

15221-1324-0-Spring-Valve

4

15221-1333-0

15221-1333-0-Retainer-Valve Spring

5

15221-1336-0

15221-1336-0-Collet Valve Spring

6

15221-1315-0

15221-1315-0-Seal Valve Stem

7

15221-1328-0

15221-1328-0-Cap-Valve

8

15401-1405-0

15401-1405-0-Assy Shaft Locker Arm
