Запчасти Hyundai HSL600 MAIN PUMP(LEFT HD. C/P)

1

422309

422309-Pump Housing

10

427172

427172-Screw

11

427171

427171-Bolt

12

423617

423617-Gasket-Housing

13

419627

419627-Bearing-T/Roller

14

416636

416636-Yoke-Swing

15

423416

423416-Shaft

16

923936

923936-Kit-Rotating Group

16A

923939

923939-. Shoe S/A Kit-Piston

16B

402650

402650-. Plate-Shoe

16C

402580

402580-. Washer-Spherical

16D

410050

410050-. Pin-Retainer

16E

248810

248810-. Pin

16F

426836

426836-. Cylinder Block

16G

404932

404932-. Washer-Spring

16H

424526

424526-. Spring

16I

423368

423368-. Washer-Spring

16J

99907

99907-. Ring-Retainer

17

942401

942401-Kit-Bearing Spacer

19

473914

473914-Bearing-T/Roller

2

471965

471965-Shaft Seal

20

416650

416650-Coupling

3

85560

85560-Retaining Ring

4

417381

417381-Bearing-T/Roller

5

410053

410053-Spacer-Pintle

6

174140

174140-O-Ring

8

416638

416638-Pintle-Cover

9

416637

416637-Cover

K

31S1-1002

31S1-1002-Hyd Pump Ass'Y

K

920171

920171-Seal Kit

N18

424481

424481-Wafer Plate

N7

923938

923938-Pintle-Shim-Kit
